7Y99

Crystal Structure Analysis of cp2 bound BCLxl


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free: 0.192
  • R-Value Work: 0.174
  • R-Value Observed: 0.175

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Cyclic peptides discriminate BCL-2 and its clinical mutants from BCL-X L by engaging a single-residue discrepancy.

Li, F.Liu, J.Liu, C.Liu, Z.Peng, X.Huang, Y.Chen, X.Sun, X.Wang, S.Chen, W.Xiong, D.Diao, X.Wang, S.Zhuang, J.Wu, C.Wu, D.

(2024) Nat Commun 15: 1476-1476

  • DOI: https://doi.org/10.1038/s41467-024-45848-1
  • Primary Citation of Related Structures:
    7Y8D, 7Y90, 7Y99, 7YA5, 7YAA, 7YB7

  • PubMed Abstract:

    Overexpressed pro-survival B-cell lymphoma-2 (BCL-2) family proteins BCL-2 and BCL-X L can render tumor cells malignant. Leukemia drug venetoclax is currently the only approved selective BCL-2 inhibitor. However, its application has led to an emergence of resistant mutations, calling for drugs with an innovative mechanism of action. Herein we present cyclic peptides (CPs) with nanomolar-level binding affinities to BCL-2 or BCL-X L , and further reveal the structural and functional mechanisms of how these CPs target two proteins in a fashion that is remarkably different from traditional small-molecule inhibitors. In addition, these CPs can bind to the venetoclax-resistant clinical BCL-2 mutants with similar affinities as to the wild-type protein. Furthermore, we identify a single-residue discrepancy between BCL-2 D111 and BCL-X L A104 as a molecular "switch" that can differently engage CPs. Our study suggests that CPs may inhibit BCL-2 or BCL-X L by delicately modulating protein-protein interactions, potentially benefiting the development of next-generation therapeutics.


  • Organizational Affiliation

    Helmholtz International Lab, State Key Laboratory of Microbial Technology, Shandong University, Qingdao, 266237, China. lifengwei@sdu.edu.cn.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Bcl-2-like protein 1141Mus musculusMutation(s): 0
Gene Names: Bcl2l1Bcl2lBclx
UniProt
Find proteins for Q64373 (Mus musculus)
Explore Q64373
Go to UniProtKB:  Q64373
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ64373
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
CP2 peptide11Homo sapiensMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
IQ8 (Subject of Investigation/LOI)
Query on IQ8

Download Ideal Coordinates CCD File
C [auth B]N-(2-acetamidoethyl)-4-(4,5-dihydro-1,3-thiazol-2-yl)benzamide
C14 H17 N3 O2 S
RTMXZJKKASUKFJ-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free: 0.192
  • R-Value Work: 0.174
  • R-Value Observed: 0.175
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 68.433α = 90
b = 100.478β = 90
c = 51.326γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
HKL-3000data scaling
PDB_EXTRACTdata extraction
HKL-3000data reduction
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China--

Revision History  (Full details and data files)

  • Version 1.0: 2023-09-27
    Type: Initial release
  • Version 1.1: 2023-11-15
    Changes: Structure summary
  • Version 1.2: 2024-02-28
    Changes: Database references
