7Y0U

Crystal structure of the P450 BM3 heme domain mutant F87A in complex with N-imidazolyl-hexanoyl-L-phenylalanyl-L-phenylalanine and hydroxylamine

• PDB DOI: https://doi.org/10.2210/pdb7Y0U/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Priestia megaterium NBRC 15308 = ATCC 14581, synthetic construct
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): Yes


• Deposited: 2022-06-06 Released: 2023-06-14
• Deposition Author(s): Jiang, Y., Dong, S., Feng, Y., Cong, Z.
• Funding Organization(s): National Natural Science Foundation of China (NSFC)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free: 0.226
• R-Value Work: 0.199
• R-Value Observed: 0.200

Literature

Crystal structure of the P450 BM3 heme domain mutant F87A in complex with N-imidazolyl-hexanoyl-L-phenylalanyl-L-phenylalanine and hydroxylamine

Jiang, Y., Dong, S., Feng, Y., Cong, Z.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 108.96 kDa
• Atom Count: 7,710
• Modelled Residue Count: 890
• Deposited Residue Count: 936
• Unique protein chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Bifunctional cytochrome P450/NADPH--P450 reductase	A, B	465	Priestia megaterium NBRC 15308 = ATCC 14581	Mutation(s): 1  Gene Names: cyp102A1, cyp102, BG04_163 EC: 1.14.14.1 (PDB Primary Data), 1.6.2.4 (PDB Primary Data)
UniProt
Find proteins for P14779 (Priestia megaterium (strain ATCC 14581 / DSM 32 / CCUG 1817 / JCM 2506 / NBRC 15308 / NCIMB 9376 / NCTC 10342 / NRRL B-14308 / VKM B-512 / Ford 19)) Explore P14779  Go to UniProtKB:  P14779

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
I7X-PHE-PHE	C, D	3	synthetic construct	Mutation(s): 0

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
HEM (Subject of Investigation/LOI)	E [auth A], G [auth B]	PROTOPORPHYRIN IX CONTAINING FE C34 H32 Fe N4 O4 KABFMIBPWCXCRK-RGGAHWMASA-L
HOA (Subject of Investigation/LOI)	F [auth A], H [auth B]	HYDROXYAMINE H3 N O AVXURJPOCDRRFD-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free: 0.226
• R-Value Work: 0.199
• R-Value Observed: 0.200
• Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 57.444	α = 90
b = 143.469	β = 98.29
c = 62.344	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
HKL-3000	data reduction
PHENIX	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2023-06-14
Deposition Author(s): Jiang, Y., Dong, S., Feng, Y., Cong, Z.

---

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	21778060
National Natural Science Foundation of China (NSFC)	China	21977104

Revision History

• Version 1.0: 2023-06-14
  Type: Initial release

• Version 1.1: 2023-11-29
  Changes: Data collection, Refinement description
