7XUV

Crystal structure of RPA70N-RMI1 fusion

• PDB DOI: https://doi.org/10.2210/pdb7XUV/pdb

• Classification: DNA BINDING PROTEIN
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2022-05-20 Released: 2023-06-14
• Deposition Author(s): Wu, Y.Y., Zang, N., Fu, W.M., Zhou, C.
• Funding Organization(s): Ministry of Education (MoE, China)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.60 Å
• R-Value Free: 0.220
• R-Value Work: 0.187
• R-Value Observed: 0.188

Literature

Structural characterization of human RPA70N association with DNA damage response proteins.

Wu, Y.Y., Zang, N., Fu, W.M., Zhou, C.

(2023) Elife 12: e81639

• DOI: https://doi.org/doi.org/10.7554/eLife.81639

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 2-mer - A1B1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 15.54 kDa
• Atom Count: 1,123
• Modelled Residue Count: 133
• Deposited Residue Count: 142
• Unique protein chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Replication protein A 70 kDa DNA-binding subunit	A	120	Homo sapiens	Mutation(s): 0  Gene Names: RPA1, REPA1, RPA70
UniProt & NIH Common Fund Data Resources
Find proteins for P27694 (Homo sapiens) Explore P27694  Go to UniProtKB:  P27694
PHAROS:  P27694 GTEx:  ENSG00000132383

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
RecQ-mediated genome instability protein 1	B	22	Homo sapiens	Mutation(s): 0  Gene Names: RMI1, C9orf76
UniProt & NIH Common Fund Data Resources
Find proteins for Q9H9A7 (Homo sapiens) Explore Q9H9A7  Go to UniProtKB:  Q9H9A7
PHAROS:  Q9H9A7 GTEx:  ENSG00000178966

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.60 Å
• R-Value Free: 0.220
• R-Value Work: 0.187
• R-Value Observed: 0.188
• Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 40.93	α = 90
b = 50.263	β = 90
c = 52.308	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2023-06-14
Deposition Author(s): Wu, Y.Y., Zang, N., Fu, W.M., Zhou, C.

---

Funding Organization	Location	Grant Number
Ministry of Education (MoE, China)	China	--

Revision History

• Version 1.0: 2023-06-14
  Type: Initial release

• Version 1.1: 2023-09-13
  Changes: Data collection, Database references
• Version 1.2: 2023-11-29
  Changes: Refinement description
