7XMJ | pdb_00007xmj

Crystal structure of carbohydrate esterase family 7 acetyl xylan esterase

PDB DOI: https://doi.org/10.2210/pdb7XMJ/pdb
Entry: 7XMJ supersedes: 7CUZ

Classification: STRUCTURAL PROTEIN
Organism(s): Lactococcus lactis subsp. lactis KF147
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2022-04-26 Released: 2023-05-31
Deposition Author(s): Jiang, Z.Q., Ma, J.W.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.41 Å
R-Value Free:
0.280 (Depositor), 0.280 (DCC)
R-Value Work:
0.248 (Depositor), 0.250 (DCC)
R-Value Observed:
0.250 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

Crystal structure of carbohydrate esterase family 7 acetyl xylan esterase

Jiang, Z.Q., Ma, J.W.

To be published.

Macromolecule Content

Total Structure Weight: 143.37 kDa
Atom Count: 10,061
Modeled Residue Count: 1,218
Deposited Residue Count: 1,248
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Acetylxylan esterase	A, B, C, D	312	Lactococcus lactis subsp. lactis KF147	Mutation(s): 0 Gene Names: axe, LLKF_1447 EC: 3.1.1
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CA Query on CA Download Ideal Coordinates CCD File SDF format, chain G [auth D] SDF format, chain F [auth C] SDF format, chain E [auth A] MOL2 format, chain G [auth D] MOL2 format, chain F [auth C] MOL2 format, chain E [auth A] mmCIF format, chain G [auth D] mmCIF format, chain F [auth C] mmCIF format, chain E [auth A]	E [auth A], F [auth C], G [auth D]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth C] Focus chain G [auth D] Interactions & Density Focus chain E [auth A] Focus chain F [auth C] Focus chain G [auth D]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.41 Å
R-Value Free: 0.280 (Depositor), 0.280 (DCC)
R-Value Work: 0.248 (Depositor), 0.250 (DCC)
R-Value Observed: 0.250 (Depositor)

Space Group: P 6₃

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 147.714	α = 90
b = 147.714	β = 90
c = 135.389	γ = 120

Software Package:

Software Name	Purpose
HKL-2000	data scaling
HKL-2000	data reduction
PHENIX	model building
PHENIX	refinement
PHENIX	phasing

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2023-05-31

Deposition Author(s):

This entry supersedes: 7CUZ

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	--

Revision History (Full details and data files)

Version 1.0: 2023-05-31
Type: Initial release
Version 1.1: 2023-11-08
Changes: Advisory, Data collection
Version 1.2: 2023-11-29
Changes: Refinement description
