7XHF

Crystal structure of the NTF2L domain of human G3BP1 in complex with the USP10 derived peptide


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.68 Å
  • R-Value Free: 0.254
  • R-Value Work: 0.210
  • R-Value Observed: 0.213

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Yin and yang regulation of stress granules by Caprin-1.

Song, D.Kuang, L.Yang, L.Wang, L.Li, H.Li, X.Zhu, Z.Shi, C.Zhu, H.Gong, W.

(2022) Proc Natl Acad Sci U S A 119: e2207975119-e2207975119

  • DOI: https://doi.org/10.1073/pnas.2207975119
  • Primary Citation of Related Structures:
    7XHF, 7XHG

  • PubMed Abstract:

    Stress granules (SGs) are cytoplasmic biomolecular condensates containing proteins and RNAs in response to stress. Ras-GTPase-activating protein binding protein 1 (G3BP1) is a core SG protein. Caprin-1 and ubiquitin specific peptidase 10 (USP10) interact with G3BP1, facilitating and suppressing SG formation, respectively. The crystal structures of the nuclear transport factor 2-like (NTF2L) domain of G3BP1 in complex with the G3BP1-interacting motif (GIM) of Caprin-1 and USP10 show that both GIMs bind to the same hydrophobic pocket of G3BP1. Moreover, both GIMs suppressed the liquid-liquid phase separation (LLPS) of G3BP1, suggesting that Caprin-1 likely facilitates SG formation via other mechanisms. Thus, we dissected various domains of Caprin-1 and investigated their role in LLPS in vitro and SG formation in cells. The C-terminal domain of Caprin-1 underwent spontaneous LLPS, whereas the N-terminal domain and GIM of Caprin-1 suppressed LLPS of G3BP1. The opposing effect of the N- and C-terminal domains of Caprin-1 on SG formation were demonstrated in cells with or without the endogenous Caprin-1. We propose that the N- and C-terminal domains of Caprin-1 regulate SG formation in a "yin and yang" fashion, mediating the dynamic and reversible assembly of SGs.


  • Organizational Affiliation

    School of Life Sciences, University of Science and Technology of China, Hefei, 230027 China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Ras GTPase-activating protein-binding protein 1
A, B
139Homo sapiensMutation(s): 0
Gene Names: G3BP1G3BP
EC: 3.6.4.12 (PDB Primary Data), 3.6.4.13 (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for Q13283 (Homo sapiens)
Explore Q13283
Go to UniProtKB:  Q13283
PHAROS:  Q13283
GTEx:  ENSG00000145907
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ13283
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
USP10/6-21
C, D
16Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for Q14694 (Homo sapiens)
Explore Q14694
Go to UniProtKB:  Q14694
PHAROS:  Q14694
GTEx:  ENSG00000103194
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ14694
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.68 Å
  • R-Value Free: 0.254
  • R-Value Work: 0.210
  • R-Value Observed: 0.213
  • Space Group: P 31 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 81.874α = 90
b = 81.874β = 90
c = 94.247γ = 120
Software Package:
Software NamePurpose
REFMACrefinement
PDB_EXTRACTdata extraction
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Ministry of Science and Technology (MoST, China)China--

Revision History  (Full details and data files)

  • Version 1.0: 2023-01-18
    Type: Initial release
  • Version 1.1: 2023-11-29
    Changes: Data collection, Refinement description
