7WZE

Structure of Transcriptional regulator from Bacillus subtilis (strain 168)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.65 Å
  • R-Value Free: 0.296
  • R-Value Work: 0.211
  • R-Value Observed: 0.216

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Structure-based molecular characterization of the YetL transcription factor from Bacillus subtilis.

Park, J.Kim, J.Choi, Z.Hong, M.

(2022) Biochem Biophys Res Commun 607: 146-151

  • DOI: https://doi.org/10.1016/j.bbrc.2022.03.133
  • Primary Citation of Related Structures:
    7WZE

  • PubMed Abstract:

    Bacillus subtilis is a gram-positive bacterium that has developed to coordinate gene expression and to survive against changes of nutrients and toxic chemicals. Flavonoids are exuded by plant cells and are abundant in the soil. To counteract the antibacterial effects of flavonoids, B. subtilis expresses flavonoid-detoxifying enzymes, and their expression is negatively regulated by transcription factors, including YetL. YetL was shown to control B. subtilis growth through the promoter regions of yetL and yetM genes in response to some flavonoids. Despite the functional significance of the YetL transcription factor in bacterial survival, no structural information is available for YetL. Here, we report the crystal structure of YetL and propose a flavonoid-induced regulatory mechanism. The YetL structure contains the canonical winged helix-turn-helix motif of the MarR superfamily but distinctly presents an additional N-terminal helix. In the dimeric assembly of YetL, the H1 helix intersects the YetL dimer and contributes to extensive intersubunit interactions. As a transcription factor, YetL recognizes a 28-mer operator of double-stranded DNA that contains a palindromic sequence. Moreover, our comparative structural analysis of YetL and other MarR members allows us to propose a flavonoid-induced transcription regulatory mechanism that is used for bacterial adaptation to environmental changes and stresses.


  • Organizational Affiliation

    Division of Biological Science and Technology, Yonsei University, Wonju, 26493, Republic of Korea.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Uncharacterized HTH-type transcriptional regulator YetLA [auth Y],
B [auth A]
167Bacillus subtilis subsp. subtilis str. 168Mutation(s): 0
Gene Names: yetLBSU07220
UniProt
Find proteins for O31541 (Bacillus subtilis (strain 168))
Explore O31541
Go to UniProtKB:  O31541
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO31541
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A [auth Y],
B [auth A]
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.65 Å
  • R-Value Free: 0.296
  • R-Value Work: 0.211
  • R-Value Observed: 0.216
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 46.178α = 90
b = 76.545β = 90
c = 88.863γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Research Foundation (NRF, Korea)Korea, Republic Of2021R1F1A1045940

Revision History  (Full details and data files)

  • Version 1.0: 2022-04-20
    Type: Initial release
