7WRN | pdb_00007wrn

ESRP1 RNaseH-qRRM1 tandem domain

PDB DOI: https://doi.org/10.2210/pdb7WRN/pdb

Classification: SPLICING
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2022-01-27 Released: 2023-02-01
Deposition Author(s): Wu, B.X., Guo, W.T., Patel, D.J.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.85 Å
R-Value Free:
0.231 (Depositor), 0.232 (DCC)
R-Value Work:
0.194 (Depositor), 0.195 (DCC)
R-Value Observed:
0.195 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7WRN

This is version 1.1 of the entry. See complete history.

Literature

ESRP1 RNaseH-qRRM1 tandem domain

Wu, B.X., Guo, W.T., Patel, D.J.

To be published.

Macromolecule Content

Total Structure Weight: 34.86 kDa
Atom Count: 2,505
Modeled Residue Count: 297
Deposited Residue Count: 310
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Epithelial splicing regulatory protein 1	A	310	Homo sapiens	Mutation(s): 0 Gene Names: ESRP1, RBM35A
UniProt & NIH Common Fund Data Resources
Find proteins for Q6NXG1 (Homo sapiens) Explore Q6NXG1 Go to UniProtKB: Q6NXG1
PHAROS: Q6NXG1 GTEx: ENSG00000104413
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q6NXG1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.85 Å
R-Value Free: 0.231 (Depositor), 0.232 (DCC)
R-Value Work: 0.194 (Depositor), 0.195 (DCC)
R-Value Observed: 0.195 (Depositor)

Space Group: P 4₂ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 70.365	α = 90
b = 70.365	β = 90
c = 114	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
SCALA	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-02-01

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2023-02-01
Type: Initial release
Version 1.1: 2023-11-29
Changes: Data collection, Refinement description
