7WNW

Crystal structure of Imine Reductase Mutant(M5) from Actinoalloteichus hymeniacidonis in complex with NADPH


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.13 Å
  • R-Value Free: 0.260
  • R-Value Work: 0.203
  • R-Value Observed: 0.206

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Tuning an Imine Reductase for the Asymmetric Synthesis of Azacycloalkylamines by Concise Structure-Guided Engineering.

Zhang, J.Liao, D.Chen, R.Zhu, F.Ma, Y.Gao, L.Qu, G.Cui, C.Sun, Z.Lei, X.Gao, S.S.

(2022) Angew Chem Int Ed Engl 61: e202201908-e202201908

  • DOI: 10.1002/anie.202201908
  • Primary Citation of Related Structures:
    7WNN, 7WNW

  • PubMed Abstract:
  • Although imine reductases (IREDs) are emerging as attractive reductive aminases (RedAms), their substrate scope is still narrow, and rational engineering is rare. Focusing on hydrogen bond reorganization and cavity expansion, a concise strategy combining rational cavity design, combinatorial active-site saturation test (CAST), and thermostability engineering was designed, that transformed the weakly active IR-G36 into a variant M5 with superior performance for the synthesis of (R)-3-benzylamino-1-Boc-piperidine, with a 4193-fold improvement in catalytic efficiency, a 16 ...

    Although imine reductases (IREDs) are emerging as attractive reductive aminases (RedAms), their substrate scope is still narrow, and rational engineering is rare. Focusing on hydrogen bond reorganization and cavity expansion, a concise strategy combining rational cavity design, combinatorial active-site saturation test (CAST), and thermostability engineering was designed, that transformed the weakly active IR-G36 into a variant M5 with superior performance for the synthesis of (R)-3-benzylamino-1-Boc-piperidine, with a 4193-fold improvement in catalytic efficiency, a 16.2 ℃ improvement in Tm, and a significant increase in the e.e. value from 78% (R) to >99% (R). M5 exhibits broad substrate scope for the synthesis of diverse azacycloalkylamines, and the reaction was demonstrated on a hectogram-scale under industrially relevant conditions. Our study provides a compelling example of the preparation of versatile and efficient IREDs, with exciting opportunities in medicinal and process chemistry as well as synthetic biology.


    Organizational Affiliation

    Chinese Academy of Sciences, Institute of Microbiology, NO.1 Beichen West Road,, Chaoyang District,, 100010, Beijing, CHINA.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
3-hydroxyisobutyrate dehydrogenase-like beta-hydroxyacid dehydrogenaseB [auth A],
A [auth B]
336Actinoalloteichus hymeniacidonisMutation(s): 10
Gene Names: BKA25_002661
UniProt
Find proteins for A0A1D8BXU6 (Actinoalloteichus hymeniacidonis)
Explore A0A1D8BXU6
Go to UniProtKB:  A0A1D8BXU6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A1D8BXU6
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
NAP (Subject of Investigation/LOI)
Query on NAP

Download Ideal Coordinates CCD File
C [auth B],
D [auth A]
NADP NICOTINAMIDE-ADENINE-DINUCLEOTIDE PHOSPHATE
C21 H28 N7 O17 P3
XJLXINKUBYWONI-NNYOXOHSSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.13 Å
  • R-Value Free: 0.260
  • R-Value Work: 0.203
  • R-Value Observed: 0.206
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 120.555α = 90
b = 62.444β = 96.753
c = 93.316γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Science Foundation (NSF, China)ChinaNSF:31872614

Revision History  (Full details and data files)

  • Version 1.0: 2022-04-06
    Type: Initial release
  • Version 1.1: 2022-04-20
    Changes: Database references
  • Version 1.2: 2022-06-08
    Changes: Database references
