7WMT

Crystal structure of small molecule 13 bound to human Nicotinamide N-methyltransferase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.77 Å
  • R-Value Free: 0.191
  • R-Value Work: 0.155
  • R-Value Observed: 0.157

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history


Literature

Peptide-to-Small Molecule: A Pharmacophore-Guided Small Molecule Lead Generation Strategy from High-Affinity Macrocyclic Peptides.

Yoshida, S.Uehara, S.Kondo, N.Takahashi, Y.Yamamoto, S.Kameda, A.Kawagoe, S.Inoue, N.Yamada, M.Yoshimura, N.Tachibana, Y.

(2022) J Med Chem 65: 10655-10673

  • DOI: https://doi.org/10.1021/acs.jmedchem.2c00919
  • Primary Citation of Related Structures:
    7WMC, 7WMT

  • PubMed Abstract:

    Recent technological innovations have led to the development of methods for the rapid identification of high-affinity macrocyclic peptides for a wide range of targets; however, it is still challenging to achieve the desired activity and membrane permeability at the same time. Here, we propose a novel small molecule lead discovery strategy, ″Peptide-to-Small Molecule″, which is a combination of rapid identification of high-affinity macrocyclic peptides via peptide display screening followed by pharmacophore-guided de novo design of small molecules, and demonstrate the applicability using nicotinamide N -methyltransferase (NNMT) as a target. Affinity selection by peptide display technology identified macrocyclic peptide 1 that exhibited good enzymatic inhibitory activity but no cell-based activity. Thereafter, a peptide pharmacophore-guided de novo design and further structure-based optimization resulted in highly potent and cell-active small molecule 14 (cell-free IC 50 = 0.0011 μM, cell-based IC 50 = 0.40 μM), indicating that this strategy could be a new option for drug discovery.


  • Organizational Affiliation

    Pharmaceutical Research Division, Shionogi Pharmaceutical Research Center, 3-1-1 Futaba-cho, Toyonaka, Osaka561-0825, Japan.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Nicotinamide N-methyltransferase250Homo sapiensMutation(s): 0
Gene Names: NNMT
EC: 2.1.1.1
UniProt & NIH Common Fund Data Resources
Find proteins for P40261 (Homo sapiens)
Explore P40261
Go to UniProtKB:  P40261
PHAROS:  P40261
GTEx:  ENSG00000166741
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP40261
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
1IV (Subject of Investigation/LOI)
Query on 1IV

Download Ideal Coordinates CCD File
B [auth A][(2~{R},4~{S})-4-[2-(aminomethyl)imidazol-1-yl]-2-[1-[(4-chlorophenyl)methyl]-5-methyl-indol-2-yl]pyrrolidin-1-yl]-(1~{H}-pyrrolo[2,3-b]pyridin-5-yl)methanone
C32 H30 Cl N7 O
IRMSFVCDJOZKRF-LITSAYRRSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.77 Å
  • R-Value Free: 0.191
  • R-Value Work: 0.155
  • R-Value Observed: 0.157
  • Space Group: P 32
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 62.654α = 90
b = 62.654β = 90
c = 67.121γ = 120
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling
MOLREPphasing
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2022-08-31
    Type: Initial release
