7W74 | pdb_00007w74

Crystal structure of DTG rhodopsin from Pseudomonas putida


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.84 Å
  • R-Value Free:
    0.256 (Depositor), 0.259 (DCC)
  • R-Value Work:
    0.229 (Depositor), 0.233 (DCC)
  • R-Value Observed:
    0.232 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7W74

Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history

Literature

Structural characterization of proton-pumping rhodopsin lacking a cytoplasmic proton donor residue by X-ray crystallography.

Suzuki, K.Del Carmen Marin, M.Konno, M.Bagherzadeh, R.Murata, T.Inoue, K.

(2022) J Biological Chem 298: 101722-101722

  • DOI: https://doi.org/10.1016/j.jbc.2022.101722
  • Primary Citation Related Structures:
    7W74

  • PubMed Abstract:

    DTG/DTS rhodopsin, which was named based on a three-residue motif (DTG or DTS) that is important for its function, is a light-driven proton-pumping microbial rhodopsin using a retinal chromophore. In contrast to other light-driven ion-pumping rhodopsins, DTG/DTS rhodopsin does not have a cytoplasmic proton donor residue, such as Asp, Glu, or Lys. Because of the lack of cytoplasmic proton donor residue, proton directly binds to the retinal chromophore from the cytoplasmic solvent. However, mutational experiments that showed the complicated effects of mutations were not able to clarify the roles played by each residue, and the detail of proton uptake pathway is unclear because of the lack of structural information. To understand the proton transport mechanism of DTG/DTS rhodopsin, here we report the three-dimensional structure of one of the DTG/DTS rhodopsins, PspR from Pseudomonas putida, by X-ray crystallography. We show that the structure of the cytoplasmic side of the protein is significantly different from that of bacteriorhodopsin, the best-characterized proton-pumping rhodopsin, and large cytoplasmic cavities were observed. We propose that these hydrophilic cytoplasmic cavities enable direct proton uptake from the cytoplasmic solvent without the need for a specialized cytoplasmic donor residue. The introduction of carboxylic residues homologous to the cytoplasmic donors in other proton-pumping rhodopsins resulted in higher pumping activity with less pH dependence, suggesting that DTG/DTS rhodopsins are advantageous for producing energy and avoiding intracellular alkalization in soil and plant-associated bacteria.


  • Organizational Affiliation
    • Department of Chemistry, Graduate School of Science, Chiba University, Inage, Chiba, Japan.

Macromolecule Content

  • Total Structure Weight: 55.07 kDa
  • Atom Count: 3,691
  • Modeled Residue Count: 452
  • Deposited Residue Count: 476
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Bacteriorhodopsin-like protein
A, B
238Pseudomonas putidaMutation(s): 0
Gene Names: F633_03659
Membrane Entity: Yes
UniProt
Find proteins for A0A8X6EH36 (Pseudomonas putida)
Explore A0A8X6EH36
Go to UniProtKB:  A0A8X6EH36
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A8X6EH36
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
OLC

Query on OLC



Download:Ideal Coordinates CCD File
E [auth A],
F [auth A],
G [auth A],
H [auth A],
K [auth B]
(2R)-2,3-dihydroxypropyl (9Z)-octadec-9-enoate
C21 H40 O4
RZRNAYUHWVFMIP-GDCKJWNLSA-N
OLB

Query on OLB



Download:Ideal Coordinates CCD File
D [auth A],
J [auth B]
(2S)-2,3-dihydroxypropyl (9Z)-octadec-9-enoate
C21 H40 O4
RZRNAYUHWVFMIP-QJRAZLAKSA-N
RET
(Subject of Investigation/LOI)

Query on RET



Download:Ideal Coordinates CCD File
C [auth A],
I [auth B]
RETINAL
C20 H28 O
NCYCYZXNIZJOKI-OVSJKPMPSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.84 Å
  • R-Value Free:  0.256 (Depositor), 0.259 (DCC)
  • R-Value Work:  0.229 (Depositor), 0.233 (DCC)
  • R-Value Observed: 0.232 (Depositor)
Space Group: P 63
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 65.565α = 90
b = 65.565β = 90
c = 219.363γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
Cootmodel building
MOLREPphasing
XDSdata reduction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Japan Society for the Promotion of Science (JSPS)Japan--

Revision History  (Full details and data files)

  • Version 1.0: 2022-02-23
    Type: Initial release
  • Version 1.1: 2022-04-20
    Changes: Database references
  • Version 1.2: 2023-11-29
    Changes: Data collection, Refinement description
  • Version 1.3: 2024-11-20
    Changes: Structure summary
