7UWF

Human Rix1 sub-complex scaffold

  • Classification: STRUCTURAL PROTEIN
  • Organism(s): Homo sapiens
  • Expression System: Homo sapiens
  • Mutation(s): No

  • Deposited: 2022-05-03 Released: 2022-11-02
  • Deposition Author(s): Gordon, J., Stanley, R.E.
  • Funding Organization(s): National Institutes of Health/National Institute of Environmental Health Sciences (NIH/NIEHS)

Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.70 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Cryo-EM reveals the architecture of the PELP1-WDR18 molecular scaffold.

Gordon, J.Chapus, F.L.Viverette, E.G.Williams, J.G.Deterding, L.J.Krahn, J.M.Borgnia, M.J.Rodriguez, J.Warren, A.J.Stanley, R.E.

(2022) Nat Commun 13: 6783-6783

  • DOI: https://doi.org/10.1038/s41467-022-34610-0
  • Primary Citation of Related Structures:
    7UWF

  • PubMed Abstract:

    PELP1 (Proline-, Glutamic acid-, Leucine-rich protein 1) is a large scaffolding protein that functions in many cellular pathways including steroid receptor (SR) coactivation, heterochromatin maintenance, and ribosome biogenesis. PELP1 is a proto-oncogene whose expression is upregulated in many human cancers, but how the PELP1 scaffold coordinates its diverse cellular functions is poorly understood. Here we show that PELP1 serves as the central scaffold for the human Rix1 complex whose members include WDR18, TEX10, and SENP3. We reconstitute the mammalian Rix1 complex and identified a stable sub-complex comprised of the conserved PELP1 Rix1 domain and WDR18. We determine a 2.7 Å cryo-EM structure of the subcomplex revealing an interconnected tetrameric assembly and the architecture of PELP1's signaling motifs, including eleven LxxLL motifs previously implicated in SR signaling and coactivation of Estrogen Receptor alpha (ERα) mediated transcription. However, the structure shows that none of these motifs is in a conformation that would support SR binding. Together this work establishes that PELP1 scaffolds the Rix1 complex, and association with WDR18 may direct PELP1's activity away from SR coactivation.


  • Organizational Affiliation

    Signal Transduction Laboratory, National Institute of Environmental Health Sciences, National Institutes of Health, Department of Health and Human Services, 111 T. W. Alexander Drive, Research Triangle Park, NC, 27709, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
WD repeat-containing protein 18A,
C [auth B]
447Homo sapiensMutation(s): 0
Gene Names: WDR18
UniProt & NIH Common Fund Data Resources
Find proteins for Q9BV38 (Homo sapiens)
Explore Q9BV38
Go to UniProtKB:  Q9BV38
PHAROS:  Q9BV38
GTEx:  ENSG00000065268
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9BV38
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Modulator of non-genomic activity of estrogen receptorB [auth C],
D
652Homo sapiensMutation(s): 0
Gene Names: PELP1
UniProt & NIH Common Fund Data Resources
Find proteins for Q8IZL8 (Homo sapiens)
Explore Q8IZL8
Go to UniProtKB:  Q8IZL8
PHAROS:  Q8IZL8
GTEx:  ENSG00000141456
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8IZL8
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.70 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONcryoSPARC3.2.0
MODEL REFINEMENTCoot

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of Environmental Health Sciences (NIH/NIEHS)United StatesZIA ES103247

Revision History  (Full details and data files)

  • Version 1.0: 2022-11-02
    Type: Initial release
  • Version 1.1: 2022-11-30
    Changes: Database references
