7UW8 | pdb_00007uw8

Drosophila melanogaster setdb1-tuor domain

• PDB DOI: https://doi.org/10.2210/pdb7UW8/pdb

• Classification: TRANSFERASE
• Organism(s): Drosophila melanogaster
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2022-05-03 Released: 2022-08-10
• Deposition Author(s): Zhou, M., Dong, A., Liu, K., Arrowsmith, C.H., Edwards, A.M., Min, J., Structural Genomics Consortium (SGC)
• Funding Organization(s): Other private

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.50 Å
• R-Value Free:
  0.276 (Depositor), 0.290 (DCC)
• R-Value Work:
  0.237 (Depositor), 0.240 (DCC)
• R-Value Observed:
  0.238 (Depositor)

Starting Model: experimental

Literature

Drosophila melanogaster setdb1-tuor domain

Zhou, M., Dong, A., Liu, K., Arrowsmith, C.H., Edwards, A.M., Min, J., Structural Genomics Consortium (SGC)

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 29.55 kDa
• Atom Count: 1,747
• Modeled Residue Count: 221
• Deposited Residue Count: 257
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Histone-lysine N-methyltransferase eggless	A	257	Drosophila melanogaster	Mutation(s): 0  Gene Names: egg, CG12196 EC: 2.1.1.355
UniProt
Find proteins for Q32KD2 (Drosophila melanogaster) Explore Q32KD2  Go to UniProtKB:  Q32KD2

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.50 Å
• R-Value Free:  0.276 (Depositor), 0.290 (DCC)
• R-Value Work:  0.237 (Depositor), 0.240 (DCC)
• R-Value Observed: 0.238 (Depositor)

Space Group: I 2 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 59.989	α = 90
b = 110.673	β = 90
c = 115.313	γ = 90

Software Package:

Software Name	Purpose
XDS	data reduction
Aimless	data scaling
BUSTER	refinement
PDB_EXTRACT	data extraction
PHASER	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2022-08-10
Deposition Author(s): Zhou, M., Dong, A., Liu, K., Arrowsmith, C.H., Edwards, A.M., Min, J., Structural Genomics Consortium (SGC)

---

Funding Organization	Location	Grant Number
Other private		--

Revision History

• Version 1.0: 2022-08-10
  Type: Initial release

• Version 1.1: 2023-10-18
  Changes: Data collection, Refinement description
