7UVS

Pfs230 domain 1 bound by LMIV230-02 Fab


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.06 Å
  • R-Value Free: 0.215
  • R-Value Work: 0.174
  • R-Value Observed: 0.175

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Potent transmission-blocking monoclonal antibodies from naturally exposed individuals target a conserved epitope on Plasmodium falciparum Pfs230.

Ivanochko, D.Fabra-Garcia, A.Teelen, K.van de Vegte-Bolmer, M.van Gemert, G.J.Newton, J.Semesi, A.de Bruijni, M.Bolscher, J.Ramjith, J.Szabat, M.Vogt, S.Kraft, L.Duncan, S.Lee, S.M.Kamya, M.R.Feeney, M.E.Jagannathan, P.Greenhouse, B.Sauerwein, R.W.Richter King, C.MacGill, R.S.Bousema, T.Jore, M.M.Julien, J.P.

(2023) Immunity 56: 420-432.e7

  • DOI: https://doi.org/10.1016/j.immuni.2023.01.013
  • Primary Citation of Related Structures:
    7UVH, 7UVI, 7UVO, 7UVQ, 7UVS

  • PubMed Abstract:

    Pfs230 is essential for Plasmodium falciparum transmission to mosquitoes and is the protein targeted by the most advanced malaria-transmission-blocking vaccine candidate. Prior understanding of functional epitopes on Pfs230 is based on two monoclonal antibodies (mAbs) with moderate transmission-reducing activity (TRA), elicited from subunit immunization. Here, we screened the B cell repertoire of two naturally exposed individuals possessing serum TRA and identified five potent mAbs from sixteen Pfs230 domain-1-specific mAbs. Structures of three potent and three low-activity antibodies bound to Pfs230 domain 1 revealed four distinct epitopes. Highly potent mAbs from natural infection recognized a common conformational epitope that is highly conserved across P. falciparum field isolates, while antibodies with negligible TRA derived from natural infection or immunization recognized three distinct sites. Our study provides molecular blueprints describing P. falciparum TRA, informed by contrasting potent and non-functional epitopes elicited by natural exposure and vaccination.


  • Organizational Affiliation

    Program in Molecular Medicine, the Hospital for Sick Children Research Institute, Toronto, ON, Canada.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
LMIV230-02 Fab heavy chain
A, D
226Homo sapiensMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
LMIV230-02 Fab light chain
B, E
221Homo sapiensMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Gametocyte surface protein P230
C, F
199Plasmodium falciparumMutation(s): 0
Gene Names: PFS230PF230S230PF3D7_0209000
UniProt
Find proteins for P68874 (Plasmodium falciparum (isolate 3D7))
Explore P68874
Go to UniProtKB:  P68874
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP68874
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
NA
Query on NA

Download Ideal Coordinates CCD File
G [auth C]SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.06 Å
  • R-Value Free: 0.215
  • R-Value Work: 0.174
  • R-Value Observed: 0.175
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 92.36α = 90
b = 132.47β = 102.348
c = 125.07γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Canadian Institutes of Health Research (CIHR)Canada428410
Ontario Early Researcher AwardsCanada--
Bill & Melinda Gates FoundationUnited StatesOPP1170236
Canada Research ChairsCanada--

Revision History  (Full details and data files)

  • Version 1.0: 2023-02-15
    Type: Initial release
  • Version 1.1: 2023-08-30
    Changes: Data collection, Database references, Refinement description
  • Version 1.2: 2023-10-25
    Changes: Refinement description
