7URK

Self-assembling DNA tensegrity triangle motif with intercalating internal Cy3 modification

  • Classification: DNA
  • Organism(s): synthetic construct
  • Mutation(s): No

  • Deposited: 2022-04-22 Released: 2023-04-26
  • Deposition Author(s): Sha, R., Vecchioni, S.
  • Funding Organization(s): Office of Naval Research (ONR), Department of Energy (DOE, United States), National Science Foundation (NSF, United States), Human Frontier Science Program (HFSP)

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.12 Å
  • R-Value Free: 0.157
  • R-Value Work: 0.155
  • R-Value Observed: 0.155

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history.


Literature

Self-assembling DNA tensegrity triangle motif with intercalating internal Cy3 modification

Sha, R., Vecchioni, S.

To be published.

Macromolecules

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 1
MoleculeChains LengthOrganismImage
DNA (5'-D(*GP*AP*GP*CP*A*(96T)P*GP*CP*CP*TP*GP*TP*A)-3')13synthetic construct
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains LengthOrganismImage
DNA (5'-D(P*AP*CP*AP*CP*CP*GP*T)-3')7synthetic construct
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 3
MoleculeChains LengthOrganismImage
DNA (5'-D(*TP*CP*TP*GP*AP*TP*GP*TP*GP*GP*CP*TP*GP*C)-3')14synthetic construct
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 4
MoleculeChains LengthOrganismImage
DNA (5'-D(P*CP*GP*GP*AP*CP*AP*TP*CP*A)-3')9synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.12 Å
  • R-Value Free: 0.157
  • R-Value Work: 0.155
  • R-Value Observed: 0.155
  • Space Group: H 3
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 113.785α = 90
b = 113.785β = 90
c = 95.709γ = 120
Software Package:
Software NamePurpose
PHASERphasing
PHENIXrefinement
autoPROCdata reduction
STARANISOdata scaling

Structure Validation

View Full Validation Report



View more in-depth experimental data
Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
Office of Naval Research (ONR)United StatesN000141912596
Department of Energy (DOE, United States)United StatesDE-SC0007991
National Science Foundation (NSF, United States)United States2106790
Human Frontier Science Program (HFSP)FranceRPG0010/2017
National Science Foundation (NSF, United States)United StatesDMR-1420073

Revision History  (Full details and data files)

  • Version 1.0: 2023-04-26
    Type: Initial release
  • Version 1.1: 2023-10-25
    Changes: Data collection, Refinement description
