7TVA

Stat5a Core in complex with AK2292


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.83 Å
  • R-Value Free: 0.246
  • R-Value Work: 0.203
  • R-Value Observed: 0.205

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

A selective small-molecule STAT5 PROTAC degrader capable of achieving tumor regression in vivo.

Kaneshige, A.Bai, L.Wang, M.McEachern, D.Meagher, J.L.Xu, R.Wang, Y.Jiang, W.Metwally, H.Kirchhoff, P.D.Zhao, L.Jiang, H.Wang, M.Wen, B.Sun, D.Stuckey, J.A.Wang, S.

(2023) Nat Chem Biol 19: 703-711

  • DOI: https://doi.org/10.1038/s41589-022-01248-4
  • Primary Citation of Related Structures:
    7TVA, 7TVB

  • PubMed Abstract:

    Signal transducer and activator of transcription 5 (STAT5) is an attractive therapeutic target, but successful targeting of STAT5 has proved to be difficult. Here we report the development of AK-2292 as a first, potent and selective small-molecule degrader of both STAT5A and STAT5B isoforms. AK-2292 induces degradation of STAT5A/B proteins with an outstanding selectivity over all other STAT proteins and more than 6,000 non-STAT proteins, leading to selective inhibition of STAT5 activity in cells. AK-2292 effectively induces STAT5 depletion in normal mouse tissues and human chronic myeloid leukemia (CML) xenograft tissues and achieves tumor regression in two CML xenograft mouse models at well-tolerated dose schedules. AK-2292 is not only a powerful research tool with which to investigate the biology of STAT5 and the therapeutic potential of selective STAT5 protein depletion and inhibition but also a promising lead compound toward ultimate development of a STAT5-targeted therapy.


  • Organizational Affiliation

    Department of Medicinal Chemistry, College of Pharmacy, University of Michigan, Ann Arbor, MI, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Signal transducer and activator of transcription 5A
A, B
573Homo sapiensMutation(s): 0
Gene Names: STAT5ASTAT5
UniProt & NIH Common Fund Data Resources
Find proteins for P42229 (Homo sapiens)
Explore P42229
Go to UniProtKB:  P42229
PHAROS:  P42229
GTEx:  ENSG00000126561
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP42229
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
KOO (Subject of Investigation/LOI)
Query on KOO

Download Ideal Coordinates CCD File
C [auth A],
E [auth B]
N-{5-[difluoro(phosphono)methyl]-1-benzothiophene-2-carbonyl}-3-methyl-L-valyl-L-prolyl-N-(5-{2-[(3R)-2,6-dioxopiperidin-3-yl]-1-oxo-2,3-dihydro-1H-isoindol-4-yl}pent-4-yn-1-yl)-N-methyl-N~3~-[4-(1,3-thiazol-2-yl)phenyl]-beta-alaninamide
C52 H54 F2 N7 O10 P S2
LOPYPDQOHNOVBM-JUDNIGJXSA-N
PEG
Query on PEG

Download Ideal Coordinates CCD File
D [auth A],
G [auth B]
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
MLI
Query on MLI

Download Ideal Coordinates CCD File
F [auth B]MALONATE ION
C3 H2 O4
OFOBLEOULBTSOW-UHFFFAOYSA-L
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.83 Å
  • R-Value Free: 0.246
  • R-Value Work: 0.203
  • R-Value Observed: 0.205
  • Space Group: H 3
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 232.476α = 90
b = 232.476β = 90
c = 112.473γ = 120
Software Package:
Software NamePurpose
BUSTERrefinement
HKL-2000data reduction
PHASERphasing
PDB_EXTRACTdata extraction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Cancer Institute (NIH/NCI)United States1-R01-CA244509

Revision History  (Full details and data files)

  • Version 1.0: 2023-02-15
    Type: Initial release
  • Version 1.1: 2023-06-07
    Changes: Database references
  • Version 1.2: 2024-04-03
    Changes: Data collection, Refinement description
