7TRW | pdb_00007trw

Crystal Structure of the C-terminal Ligand-Binding Domain of the LysR family Transcriptional Regulator YfbA from Yersinia pestis

PDB DOI: https://doi.org/10.2210/pdb7TRW/pdb

Classification: TRANSCRIPTION
Organism(s): Yersinia pestis CO92
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2022-01-31 Released: 2022-02-09
Deposition Author(s): Kim, Y., Tesar, C., Crawford, M., Endres, M., Babnigg, G., Schneewind, O., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.28 Å
R-Value Free:
0.234 (Depositor), 0.231 (DCC)
R-Value Work:
0.198 (Depositor), 0.198 (DCC)
R-Value Observed:
0.200 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 7TRW

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Crystal Structure of the C-terminal Ligand-Binding Domain of the LysR family Transcriptional Regulator YfbA from Yersinia pestis

Kim, Y., Tesar, C., Crawford, M., Endres, M., Babnigg, G., Schneewind, O., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

To be published.

Macromolecule Content

Total Structure Weight: 24.25 kDa
Atom Count: 1,764
Modeled Residue Count: 213
Deposited Residue Count: 217
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
LysR-family transcriptional regulatory protein	A	217	Yersinia pestis CO92	Mutation(s): 0 Gene Names: lysR10, y2171, YP_1951
UniProt
Find proteins for A0A380PDL3 (Yersinia pestis) Explore A0A380PDL3 Go to UniProtKB: A0A380PDL3
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A380PDL3
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
3HB (Subject of Investigation/LOI) Query on 3HB Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	3-HYDROXYBENZOIC ACID C₇ H₆ O₃ IJFXRHURBJZNAO-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
PO4 Query on PO4 Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	PHOSPHATE ION O₄ P NBIIXXVUZAFLBC-UHFFFAOYSA-K		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.28 Å
R-Value Free: 0.234 (Depositor), 0.231 (DCC)
R-Value Work: 0.198 (Depositor), 0.198 (DCC)
R-Value Observed: 0.200 (Depositor)

Space Group: P 6₂

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 86.073	α = 90
b = 86.073	β = 90
c = 69.28	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
MLPHARE	phasing
SHELXD	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2022-02-09

Deposition Author(s):

Center for Structural Genomics of Infectious Diseases (CSGID)

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	--

Revision History (Full details and data files)

Version 1.0: 2022-02-09
Type: Initial release
Version 1.1: 2024-11-13
Changes: Data collection, Structure summary
