7TBU

Crystal structure of the 5-enolpyruvate-shikimate-3-phosphate synthase (EPSPS) domain of Aro1 from Candida albicans in complex with shikimate-3-phosphate


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.85 Å
  • R-Value Free: 0.229
  • R-Value Work: 0.180
  • R-Value Observed: 0.182

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Molecular analysis and essentiality of Aro1 shikimate biosynthesis multi-enzyme in Candida albicans.

Stogios, P.J.Liston, S.D.Semper, C.Quade, B.Michalska, K.Evdokimova, E.Ram, S.Otwinowski, Z.Borek, D.Cowen, L.E.Savchenko, A.

(2022) Life Sci Alliance 5

  • DOI: 10.26508/lsa.202101358
  • Primary Citation of Related Structures:
    6C5C, 7TBU, 7TBV, 7U5S, 7U5T, 7U5U

  • PubMed Abstract:
  • In the human fungal pathogen Candida albicans , ARO1 encodes an essential multi-enzyme that catalyses consecutive steps in the shikimate pathway for biosynthesis of chorismate, a precursor to folate and the aromatic amino acids. We obtained the first molecular image of C ...

    In the human fungal pathogen Candida albicans , ARO1 encodes an essential multi-enzyme that catalyses consecutive steps in the shikimate pathway for biosynthesis of chorismate, a precursor to folate and the aromatic amino acids. We obtained the first molecular image of C. albicans Aro1 that reveals the architecture of all five enzymatic domains and their arrangement in the context of the full-length protein. Aro1 forms a flexible dimer allowing relative autonomy of enzymatic function of the individual domains. Our activity and in cellulo data suggest that only four of Aro1's enzymatic domains are functional and essential for viability of C. albicans , whereas the 3-dehydroquinate dehydratase (DHQase) domain is inactive because of active site substitutions. We further demonstrate that in C. albicans , the type II DHQase Dqd1 can compensate for the inactive DHQase domain of Aro1, suggesting an unrecognized essential role for this enzyme in shikimate biosynthesis. In contrast, in Candida glabrata and Candida parapsilosis , which do not encode a Dqd1 homolog, Aro1 DHQase domains are enzymatically active, highlighting diversity across Candida species.


    Organizational Affiliation

    Department of Microbiology, Immunology and Infectious Diseases, University of Calgary, Calgary, Canada.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
5-enolpyruvylshikimate-3-phosphate synthaseA, B458Candida albicans Ca6Mutation(s): 0
EC: 4.2.3.4 (UniProt), 2.5.1.19 (UniProt), 2.7.1.71 (UniProt), 4.2.1.10 (UniProt), 1.1.1.25 (UniProt)
UniProt
Find proteins for Q5AME2 (Candida albicans (strain SC5314 / ATCC MYA-2876))
Explore Q5AME2
Go to UniProtKB:  Q5AME2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5AME2
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
S3P (Subject of Investigation/LOI)
Query on S3P

Download Ideal Coordinates CCD File
D [auth A],
F [auth B]
SHIKIMATE-3-PHOSPHATE
C7 H11 O8 P
QYOJSKGCWNAKGW-PBXRRBTRSA-N
 Ligand Interaction
TRS
Query on TRS

Download Ideal Coordinates CCD File
C [auth A],
E [auth B]
2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL
C4 H12 N O3
LENZDBCJOHFCAS-UHFFFAOYSA-O
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.85 Å
  • R-Value Free: 0.229
  • R-Value Work: 0.180
  • R-Value Observed: 0.182
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 44.987α = 90
b = 159.754β = 92.275
c = 55.874γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-3000data reduction
HKL-3000data scaling
PHASERphasing
PHENIXmodel building
Cootmodel building

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesHHSN272201700060C

Revision History  (Full details and data files)

  • Version 1.0: 2022-03-16
    Type: Initial release
  • Version 1.1: 2022-11-23
    Changes: Database references
