7TA9 | pdb_00007ta9

Crystal Structure of thymidylate synthase from Acinetobacter baumannii

• PDB DOI: https://doi.org/10.2210/pdb7TA9/pdb

• Classification: TRANSFERASE
• Organism(s): Acinetobacter baumannii
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2021-12-20 Released: 2022-01-26
• Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease, Seattle Structural Genomics Center for Infectious Disease (SSGCID)
• Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.50 Å
• R-Value Free:
  0.191 (Depositor), 0.190 (DCC)
• R-Value Work:
  0.162 (Depositor), 0.160 (DCC)
• R-Value Observed:
  0.163 (Depositor)

Starting Model: experimental

Literature

Crystal Structure of thymidylate synthase from Acinetobacter baumannii

Bolejack, M.J., Dranow, D.M., Lorimer, D.D., Horanyi, P.S., Edwards, T.E.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 66.28 kDa
• Atom Count: 4,983
• Modeled Residue Count: 535
• Deposited Residue Count: 576
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Thymidylate synthase	A, B	288	Acinetobacter baumannii	Mutation(s): 0  Gene Names: thyA, thyA_1 EC: 2.1.1.45
UniProt
Find proteins for B7I4U0 (Acinetobacter baumannii (strain AB0057)) Explore B7I4U0  Go to UniProtKB:  B7I4U0

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PG4	F [auth A]	TETRAETHYLENE GLYCOL C8 H18 O5 UWHCKJMYHZGTIT-UHFFFAOYSA-N
PEG	G [auth B]	DI(HYDROXYETHYL)ETHER C4 H10 O3 MTHSVFCYNBDYFN-UHFFFAOYSA-N
EDO	C [auth A], D [auth A], E [auth A]	1,2-ETHANEDIOL C2 H6 O2 LYCAIKOWRPUZTN-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.50 Å
• R-Value Free:  0.191 (Depositor), 0.190 (DCC)
• R-Value Work:  0.162 (Depositor), 0.160 (DCC)
• R-Value Observed: 0.163 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 64.94	α = 90
b = 73.76	β = 90
c = 109.38	γ = 90

Software Package:

Software Name	Purpose
XDS	data reduction
XSCALE	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
MoRDa	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2022-01-26
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease, Seattle Structural Genomics Center for Infectious Disease (SSGCID)

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	--

Revision History

• Version 1.0: 2022-01-26
  Type: Initial release

• Version 1.1: 2023-10-18
  Changes: Data collection, Refinement description
