7T9T | pdb_00007t9t

Cryo-EM structure of CH235.12 in complex with HIV-1 Env trimer CH505TF.N279K.SOSIP.664 with complex glycans

• PDB DOI: https://doi.org/10.2210/pdb7T9T/pdb
• EM Map EMD-25767: EMDB EMDataResource

• Classification: VIRAL PROTEIN/IMMUNE SYSTEM
• Organism(s): Human immunodeficiency virus 1, Homo sapiens
• Expression System: Homo sapiens
• Mutation(s): No


• Deposited: 2021-12-20 Released: 2023-08-16
• Deposition Author(s): Manne, K., Acharya, P.
• Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 3.70 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Starting Models: experimental

Literature

Cryo-EM structure of CH235.12 in complex with HIV-1 Env trimer CH505TF.N279K.G458Y.SOSIP.664

Manne, K.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C3  (Explore in 3D)
Global Stoichiometry: Hetero 12-mer - A3B3C3D3

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: microscopy

Macromolecule Content

• Total Structure Weight: 366.47 kDa
• Atom Count: 24,065
• Modeled Residue Count: 2,976
• Deposited Residue Count: 3,177
• Unique protein chains: 4

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Envelope glycoprotein gp160	A, E, I	461	Human immunodeficiency virus 1	Mutation(s): 0  Gene Names: env
UniProt
Find proteins for M4M0W3 (Human immunodeficiency virus type 1) Explore M4M0W3  Go to UniProtKB:  M4M0W3
Glycosylation
Glycosylation Sites: 8

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Envelope glycoprotein gp41	B, F, J	160	Human immunodeficiency virus 1	Mutation(s): 0  Gene Names: env
UniProt
Find proteins for Q2N0S5 (Human immunodeficiency virus type 1) Explore Q2N0S5  Go to UniProtKB:  Q2N0S5

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
CH235.12 Fab Heavy Chain	C, G, K	225	Homo sapiens	Mutation(s): 0

Entity ID: 4
Molecule	Chains	Sequence Length	Organism	Details	Image
CH235.12 Fab Light Chain	D, H, L	213	Homo sapiens	Mutation(s): 0

Oligosaccharides

Help

Entity ID: 5
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	M [auth a], S [auth O], Y [auth U]	4		N-Glycosylation
Glycosylation Resources
GlyTouCan:  G95663PY GlyCosmos:  G95663PY

Entity ID: 6
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	DA [auth Z], N [auth b], R [auth N], T [auth P], X [auth T], Z [auth V]	2		N-Glycosylation
Glycosylation Resources
GlyTouCan:  G42666HT GlyCosmos:  G42666HT GlyGen:  G42666HT

Entity ID: 7
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	AA [auth W], CA [auth Y], O [auth c], Q [auth M], U [auth Q], W [auth S]	3		N-Glycosylation
Glycosylation Resources
GlyTouCan:  G15407YE GlyCosmos:  G15407YE GlyGen:  G15407YE

Entity ID: 8
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
alpha-D-mannopyranose-(1-6)-alpha-D-mannopyranose-(1-6)-[alpha-D-mannopyranose-(1-3)]beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	BA [auth X], P [auth d], V [auth R]	6		N-Glycosylation
Glycosylation Resources
GlyTouCan:  G34442SS GlyCosmos:  G34442SS GlyGen:  G34442SS

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
NAG (Subject of Investigation/LOI)	EA [auth A], FA [auth A], GA [auth E], HA [auth E], IA [auth I], JA [auth I]	2-acetamido-2-deoxy-beta-D-glucopyranose C8 H15 N O6 OVRNDRQMDRJTHS-FMDGEEDCSA-N

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 3.70 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	Coot
MODEL REFINEMENT	PHENIX
MODEL REFINEMENT	ISOLDE
RECONSTRUCTION	cryoSPARC

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2023-08-16
Deposition Author(s): Manne, K., Acharya, P.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	AI45687

Revision History

• Version 1.0: 2023-08-16
  Type: Initial release

• Version 1.1: 2024-10-16
  Changes: Data collection, Refinement description, Structure summary
