7T24 | pdb_00007t24

Crystal Structure of Adenylosuccinate lyase (ASL) from Pseudomonas aeruginosa

PDB DOI: https://doi.org/10.2210/pdb7T24/pdb

Classification: LYASE
Organism(s): Pseudomonas aeruginosa
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2021-12-03 Released: 2021-12-15
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease, Seattle Structural Genomics Center for Infectious Disease (SSGCID)
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.45 Å
R-Value Free:
0.182 (Depositor), 0.201 (DCC)
R-Value Work:
0.151 (Depositor)
R-Value Observed:
0.152 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 7T24

This is version 1.1 of the entry. See complete history.

Literature

Crystal Structure of Adenylosuccinate lyase (ASL) from Pseudomonas aeruginosa

Dranow, D.M., Abendroth, J., Lorimer, D.D., Horanyi, P.S., Edwards, T.E.

To be published.

Macromolecule Content

Total Structure Weight: 51.84 kDa
Atom Count: 3,863
Modeled Residue Count: 432
Deposited Residue Count: 464
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Adenylosuccinate lyase	A	464	Pseudomonas aeruginosa	Mutation(s): 0 Gene Names: purB, PA2629 EC: 4.3.2.2
UniProt
Find proteins for Q9I0K9 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1)) Explore Q9I0K9 Go to UniProtKB: Q9I0K9
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9I0K9
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
IMD Query on IMD Download:Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	IMIDAZOLE C₃ H₅ N₂ RAXXELZNTBOGNW-UHFFFAOYSA-O		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]
IPA Query on IPA Download:Ideal Coordinates CCD File SDF format, chain B [auth A] SDF format, chain D [auth A] SDF format, chain C [auth A] MOL2 format, chain B [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] mmCIF format, chain B [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A]	B [auth A], C [auth A], D [auth A]	ISOPROPYL ALCOHOL C₃ H₈ O KFZMGEQAYNKOFK-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.45 Å
R-Value Free: 0.182 (Depositor), 0.201 (DCC)
R-Value Work: 0.151 (Depositor)
R-Value Observed: 0.152 (Depositor)

Diffraction Data:

Space Group: I 2 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 66.56	α = 90
b = 96.55	β = 90
c = 137.58	γ = 90

Software Package:

Software Name	Purpose
XDS	data reduction
XSCALE	data scaling
PHASER	phasing
PHENIX	refinement
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2021-12-15

Deposition Author(s):

Seattle Structural Genomics Center for Infectious Disease

Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	--

Revision History (Full details and data files)

Version 1.0: 2021-12-15
Type: Initial release
Version 1.1: 2024-02-28
Changes: Data collection
