7SIZ

C-type inactivation in a voltage gated K+ channel


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.10 Å
  • R-Value Free: 0.265
  • R-Value Work: 0.236
  • R-Value Observed: 0.237

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Structural basis for C-type inactivation in a Shaker family voltage-gated K + channel.

Reddi, R.Matulef, K.Riederer, E.A.Whorton, M.R.Valiyaveetil, F.I.

(2022) Sci Adv 8: eabm8804-eabm8804

  • DOI: https://doi.org/10.1126/sciadv.abm8804
  • Primary Citation of Related Structures:
    7SIT, 7SIZ

  • PubMed Abstract:

    C-type inactivation is a process by which ion flux through a voltage-gated K + (K v ) channel is regulated at the selectivity filter. While prior studies have indicated that C-type inactivation involves structural changes at the selectivity filter, the nature of the changes has not been resolved. Here, we report the crystal structure of the K v 1.2 channel in a C-type inactivated state. The structure shows that C-type inactivation involves changes in the selectivity filter that disrupt the outer two ion binding sites in the filter. The changes at the selectivity filter propagate to the extracellular mouth and the turret regions of the channel pore. The structural changes observed are consistent with the functional hallmarks of C-type inactivation. This study highlights the intricate interplay between K + occupancy at the ion binding sites and the interactions of the selectivity filter in determining the balance between the conductive and the inactivated conformations of the filter.


  • Organizational Affiliation

    Program in Chemical Biology, Department of Chemical Physiology and Biochemistry, Oregon Health & Science University, 3181 SW Sam Jackson Park Rd, Portland, OR 97239, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Voltage-gated potassium channel subunit beta-2
A, C
333Rattus norvegicusMutation(s): 0
Gene Names: Kcnab2Ckbeta2Kcnb3
EC: 1.1.1
Membrane Entity: Yes
UniProt
Find proteins for P62483 (Rattus norvegicus)
Explore P62483
Go to UniProtKB:  P62483
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP62483
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Voltage gated potassium channel Kv1.2-Kv2.1
B, D
514Rattus norvegicusMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P63142 (Rattus norvegicus)
Explore P63142
Go to UniProtKB:  P63142
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP63142
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
NAP
Query on NAP

Download Ideal Coordinates CCD File
E [auth A],
L [auth C]
NADP NICOTINAMIDE-ADENINE-DINUCLEOTIDE PHOSPHATE
C21 H28 N7 O17 P3
XJLXINKUBYWONI-NNYOXOHSSA-N
K (Subject of Investigation/LOI)
Query on K

Download Ideal Coordinates CCD File
F [auth B]
G [auth B]
H [auth B]
I [auth B]
J [auth B]
F [auth B],
G [auth B],
H [auth B],
I [auth B],
J [auth B],
K [auth B],
M [auth D],
N [auth D],
O [auth D],
P [auth D],
Q [auth D],
R [auth D]
POTASSIUM ION
K
NPYPAHLBTDXSSS-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.10 Å
  • R-Value Free: 0.265
  • R-Value Work: 0.236
  • R-Value Observed: 0.237
  • Space Group: P 4 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 130.732α = 90
b = 130.732β = 90
c = 278.858γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
PHENIXrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01GM087546

Revision History  (Full details and data files)

  • Version 1.0: 2022-05-04
    Type: Initial release
  • Version 1.1: 2023-10-18
    Changes: Data collection, Refinement description
