7S2Y

SAMHD1 HD domain bound to CNDAC

  • Classification: HYDROLASE
  • Organism(s): Homo sapiens
  • Expression System: Escherichia coli
  • Mutation(s): Yes

  • Deposited: 2021-09-04 Released: 2021-10-27
  • Deposition Author(s): Digianantonio, K.M., Xiong, Y.
  • Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.232
  • R-Value Work: 0.186
  • R-Value Observed: 0.188

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Differences between intrinsic and acquired nucleoside analogue resistance in acute myeloid leukaemia cells.

Rothenburger, T.Thomas, D.Schreiber, Y.Wratil, P.R.Pflantz, T.Knecht, K.Digianantonio, K.Temple, J.Schneider, C.Baldauf, H.M.McLaughlin, K.M.Rothweiler, F.Bilen, B.Farmand, S.Bojkova, D.Costa, R.Ferreiros, N.Geisslinger, G.Oellerich, T.Xiong, Y.Keppler, O.T.Wass, M.N.Michaelis, M.Cinatl Jr., J.

(2021) J Exp Clin Cancer Res 40: 317-317

  • DOI: https://doi.org/10.1186/s13046-021-02093-4
  • Primary Citation of Related Structures:
    7S2Y

  • PubMed Abstract:

    SAMHD1 mediates resistance to anti-cancer nucleoside analogues, including cytarabine, decitabine, and nelarabine that are commonly used for the treatment of leukaemia, through cleavage of their triphosphorylated forms. Hence, SAMHD1 inhibitors are promising candidates for the sensitisation of leukaemia cells to nucleoside analogue-based therapy. Here, we investigated the effects of the cytosine analogue CNDAC, which has been proposed to be a SAMHD1 inhibitor, in the context of SAMHD1. CNDAC was tested in 13 acute myeloid leukaemia (AML) cell lines, in 26 acute lymphoblastic leukaemia (ALL) cell lines, ten AML sublines adapted to various antileukaemic drugs, 24 single cell-derived clonal AML sublines, and primary leukaemic blasts from 24 AML patients. Moreover, 24 CNDAC-resistant sublines of the AML cell lines HL-60 and PL-21 were established. The SAMHD1 gene was disrupted using CRISPR/Cas9 and SAMHD1 depleted using RNAi, and the viral Vpx protein. Forced DCK expression was achieved by lentiviral transduction. SAMHD1 promoter methylation was determined by PCR after treatment of genomic DNA with the methylation-sensitive HpaII endonuclease. Nucleoside (analogue) triphosphate levels were determined by LC-MS/MS. CNDAC interaction with SAMHD1 was analysed by an enzymatic assay and by crystallisation. Although the cytosine analogue CNDAC was anticipated to inhibit SAMHD1, SAMHD1 mediated intrinsic CNDAC resistance in leukaemia cells. Accordingly, SAMHD1 depletion increased CNDAC triphosphate (CNDAC-TP) levels and CNDAC toxicity. Enzymatic assays and crystallisation studies confirmed CNDAC-TP to be a SAMHD1 substrate. In 24 CNDAC-adapted acute myeloid leukaemia (AML) sublines, resistance was driven by DCK (catalyses initial nucleoside phosphorylation) loss. CNDAC-adapted sublines displayed cross-resistance only to other DCK substrates (e.g. cytarabine, decitabine). Cell lines adapted to drugs not affected by DCK or SAMHD1 remained CNDAC sensitive. In cytarabine-adapted AML cells, increased SAMHD1 and reduced DCK levels contributed to cytarabine and CNDAC resistance. Intrinsic and acquired resistance to CNDAC and related nucleoside analogues are driven by different mechanisms. The lack of cross-resistance between SAMHD1/ DCK substrates and non-substrates provides scope for next-line therapies after treatment failure.


  • Organizational Affiliation

    Institute for Medical Virology, Goethe-University, Frankfurt am Main, Germany.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Deoxynucleoside triphosphate triphosphohydrolase SAMHD1
A, B, C, D
550Homo sapiensMutation(s): 2
Gene Names: SAMHD1MOP5
EC: 3.1.5
UniProt & NIH Common Fund Data Resources
Find proteins for Q9Y3Z3 (Homo sapiens)
Explore Q9Y3Z3
Go to UniProtKB:  Q9Y3Z3
PHAROS:  Q9Y3Z3
GTEx:  ENSG00000101347
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9Y3Z3
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
GTP
Query on GTP

Download Ideal Coordinates CCD File
I [auth B],
O [auth C],
T [auth D],
V [auth D]
GUANOSINE-5'-TRIPHOSPHATE
C10 H16 N5 O14 P3
XKMLYUALXHKNFT-UUOKFMHZSA-N
85T (Subject of Investigation/LOI)
Query on 85T

Download Ideal Coordinates CCD File
E [auth A],
J [auth B],
P [auth C],
W [auth D]
4-amino-1-{2-cyano-2-deoxy-5-O-[(S)-hydroxy{[(S)-hydroxy(phosphonooxy)phosphoryl]oxy}phosphoryl]-beta-D-arabinofuranosyl}pyrimidin-2(1H)-one
C10 H15 N4 O13 P3
DZFZBFCEJVKCLY-JWIUVKOKSA-N
DTP
Query on DTP

Download Ideal Coordinates CCD File
F [auth A],
K [auth B],
N [auth C],
U [auth D]
2'-DEOXYADENOSINE 5'-TRIPHOSPHATE
C10 H16 N5 O12 P3
SUYVUBYJARFZHO-RRKCRQDMSA-N
MG
Query on MG

Download Ideal Coordinates CCD File
G [auth A]
H [auth A]
L [auth B]
M [auth B]
Q [auth C]
G [auth A],
H [auth A],
L [auth B],
M [auth B],
Q [auth C],
R [auth C],
S [auth C],
X [auth D]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.232
  • R-Value Work: 0.186
  • R-Value Observed: 0.188
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 85.84α = 90
b = 146.167β = 114.27
c = 99.587γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling
REFMACphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United States--

Revision History  (Full details and data files)

  • Version 1.0: 2021-10-27
    Type: Initial release
  • Version 1.1: 2023-10-18
    Changes: Data collection, Refinement description
