7S0G | pdb_00007s0g

Isoproterenol bound beta1 adrenergic receptor in complex with heterotrimeric Gi/s chimera protein


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.86 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 7S0G

This is version 1.2 of the entry. See complete history

Literature

Structural basis and mechanism of activation of two different families of G proteins by the same GPCR.

Alegre, K.O.Paknejad, N.Su, M.Lou, J.S.Huang, J.Jordan, K.D.Eng, E.T.Meyerson, J.R.Hite, R.K.Huang, X.Y.

(2021) Nat Struct Mol Biol 28: 936-944

  • DOI: https://doi.org/10.1038/s41594-021-00679-2
  • Primary Citation Related Structures:
    7S0F, 7S0G

  • PubMed Abstract:

    The β 1 -adrenergic receptor (β 1 -AR) can activate two families of G proteins. When coupled to Gs, β 1 -AR increases cardiac output, and coupling to Gi leads to decreased responsiveness in myocardial infarction. By comparative structural analysis of turkey β 1 -AR complexed with either Gi or Gs, we investigate how a single G-protein-coupled receptor simultaneously signals through two G proteins. We find that, although the critical receptor-interacting C-terminal α5-helices on Gα i and Gα s interact similarly with β 1 -AR, the overall interacting modes between β 1 -AR and G proteins vary substantially. Functional studies reveal the importance of the differing interactions and provide evidence that the activation efficacy of G proteins by β 1 -AR is determined by the entire three-dimensional interaction surface, including intracellular loops 2 and 4 (ICL2 and ICL4).


  • Organizational Affiliation
    • Department of Physiology and Biophysics, Weill Cornell Medical College of Cornell University, New York, NY, USA.

Macromolecule Content

  • Total Structure Weight: 146.67 kDa
  • Atom Count: 6,992
  • Modeled Residue Count: 893
  • Deposited Residue Count: 1,297
  • Unique protein chains: 4

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Beta1-Adrenergic ReceptorA [auth R]508Meleagris gallopavoMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P07700 (Meleagris gallopavo)
Explore P07700
Go to UniProtKB:  P07700
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP07700
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1339Bos taurusMutation(s): 0
Gene Names: GNB1
UniProt
Find proteins for P62871 (Bos taurus)
Explore P62871
Go to UniProtKB:  P62871
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP62871
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Guanine nucleotide-binding protein G(i) subunit alpha-1,Guanine nucleotide-binding protein G(s) subunit alpha isoforms short chimeraC [auth A]379Rattus norvegicusBos taurus
This entity is chimeric
Mutation(s): 1
Gene Names: Gnai1Gnai-1GNASGNAS1
EC: 3.6.5
Membrane Entity: Yes
UniProt
Find proteins for P04896 (Bos taurus)
Explore P04896
Go to UniProtKB:  P04896
Find proteins for P10824 (Rattus norvegicus)
Explore P10824
Go to UniProtKB:  P10824
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupsP04896P10824
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit gamma-2D [auth G]71Bos taurusMutation(s): 1
Gene Names: GNG2
Membrane Entity: Yes
UniProt
Find proteins for P63212 (Bos taurus)
Explore P63212
Go to UniProtKB:  P63212
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP63212
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
5FW
(Subject of Investigation/LOI)

Query on 5FW



Download:Ideal Coordinates CCD File
E [auth R]ISOPRENALINE
C11 H17 N O3
JWZZKOKVBUJMES-NSHDSACASA-N

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.86 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM138676

Revision History  (Full details and data files)

  • Version 1.0: 2021-11-17
    Type: Initial release
  • Version 1.1: 2021-12-01
    Changes: Database references
  • Version 1.2: 2024-10-30
    Changes: Data collection, Structure summary
