7RUZ

Crystal structure of the BCL6 BTB domain in complex with OICR-8445

• PDB DOI: https://doi.org/10.2210/pdb7RUZ/pdb

• Classification: TRANSCRIPTION/TRANSCRIPTION INHIBITOR
• Organism(s): Homo sapiens
• Expression System: Escherichia coli BL21
• Mutation(s): Yes


• Deposited: 2021-08-18 Released: 2022-11-09
• Deposition Author(s): Kuntz, D.A., Prive, G.G.
• Funding Organization(s): Ontario Institute for Cancer Research

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.62 Å
• R-Value Free: 0.233
• R-Value Work: 0.195
• R-Value Observed: 0.197

Literature

Crystal structure of the BCL6 BTB domain in complex with OICR-8445

Watson, I., Isaac, M.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: homology

Macromolecule Content

• Total Structure Weight: 15.19 kDa
• Atom Count: 1,134
• Modelled Residue Count: 122
• Deposited Residue Count: 127
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
B-cell lymphoma 6 protein	A	127	Homo sapiens	Mutation(s): 3  Gene Names: BCL6, BCL5, LAZ3, ZBTB27, ZNF51
UniProt & NIH Common Fund Data Resources
Find proteins for P41182 (Homo sapiens) Explore P41182  Go to UniProtKB:  P41182
PHAROS:  P41182 GTEx:  ENSG00000113916

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
7S5 (Subject of Investigation/LOI)	B [auth A]	2-[2-(benzylamino)-4-oxo-3,4-dihydro-7H-pyrrolo[2,3-d]pyrimidin-7-yl]-N-(3-chloropyridin-4-yl)acetamide C20 H17 Cl N6 O2 MXZBBTDICSGIKS-UHFFFAOYSA-N
FMT	C [auth A], D [auth A], E [auth A], F [auth A]	FORMIC ACID C H2 O2 BDAGIHXWWSANSR-UHFFFAOYSA-N
CL	G [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.62 Å
• R-Value Free: 0.233
• R-Value Work: 0.195
• R-Value Observed: 0.197
• Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 30.593	α = 90
b = 72.55	β = 107.183
c = 55.409	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
SCALA	data scaling
PHASER	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2022-11-09
Deposition Author(s): Kuntz, D.A., Prive, G.G.

---

Funding Organization	Location	Grant Number
Ontario Institute for Cancer Research		--

Revision History

• Version 1.0: 2022-11-09
  Type: Initial release

• Version 1.1: 2023-10-18
  Changes: Data collection, Refinement description
