7RHE | pdb_00007rhe

Crystal Structure of ROK family protein from Burkholderia vietnamiensis G4

PDB DOI: https://doi.org/10.2210/pdb7RHE/pdb

Classification: TRANSCRIPTION
Organism(s): Burkholderia vietnamiensis G4
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2021-07-16 Released: 2021-11-17
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.30 Å
R-Value Free:
0.249 (Depositor), 0.249 (DCC)
R-Value Work:
0.199 (Depositor), 0.200 (DCC)
R-Value Observed:
0.205 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7RHE

This is version 1.1 of the entry. See complete history.

Literature

Crystal Structure of ROK family protein from Burkholderia vietnamiensis G4

Abendroth, J., Delker, S.L., Lorimer, D.D., Horanyi, P.S., Edwards, T.E.

To be published.

Macromolecule Content

Total Structure Weight: 45.04 kDa
Atom Count: 2,736
Modeled Residue Count: 368
Deposited Residue Count: 423
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
ROK family protein	A	423	Burkholderia vietnamiensis G4	Mutation(s): 0 Gene Names: Bcep1808_1509
UniProt
Find proteins for A4JE13 (Burkholderia vietnamiensis (strain G4 / LMG 22486)) Explore A4JE13 Go to UniProtKB: A4JE13
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A4JE13
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.30 Å
R-Value Free: 0.249 (Depositor), 0.249 (DCC)
R-Value Work: 0.199 (Depositor), 0.200 (DCC)
R-Value Observed: 0.205 (Depositor)

Diffraction Data:

Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 112.41	α = 90
b = 112.41	β = 90
c = 63.09	γ = 120

Software Package:

Software Name	Purpose
XDS	data reduction
XSCALE	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2021-11-17

Deposition Author(s):

Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Revision History (Full details and data files)

Version 1.0: 2021-11-17
Type: Initial release
Version 1.1: 2024-04-03
Changes: Data collection, Refinement description
