7R7H | pdb_00007r7h

Peptidomimetic nitrile warheads as SARS-CoV-2 3CL protease inhibitors


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.15 Å
  • R-Value Free:
    0.259 (Depositor), 0.288 (DCC)
  • R-Value Work:
    0.203 (Depositor)
  • R-Value Observed:
    0.206 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7R7H

Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history

Literature

Peptidomimetic nitrile warheads as SARS-CoV-2 3CL protease inhibitors.

Bai, B.Arutyunova, E.Khan, M.B.Lu, J.Joyce, M.A.Saffran, H.A.Shields, J.A.Kandadai, A.S.Belovodskiy, A.Hena, M.Vuong, W.Lamer, T.Young, H.S.Vederas, J.C.Tyrrell, D.L.Lemieux, M.J.Nieman, J.A.

(2021) RSC Med Chem 12: 1722-1730

  • DOI: https://doi.org/10.1039/d1md00247c
  • Primary Citation Related Structures:
    7R7H

  • PubMed Abstract:

    Tragically, the death toll from the COVID-19 pandemic continues to rise, and with variants being observed around the globe new therapeutics, particularly direct-acting antivirals that are easily administered, are desperately needed. Studies targeting the SARS-CoV-2 3CL protease, which is critical for viral replication, with different peptidomimetics and warheads is an active area of research for development of potential drugs. To date, however, only a few publications have evaluated the nitrile warhead as a viral 3CL protease inhibitor, with only modest activity reported. This article describes our investigation of P3 4-methoxyindole peptidomimetic analogs with select P1 and P2 groups with a nitrile warhead that are potent inhibitors of SARS-CoV-2 3CL protease and demonstrate in vitro SARS-CoV-2 antiviral activity. A selectivity for SARS-CoV-2 3CL protease over human cathepsins B, S and L was also observed with the nitrile warhead, which was superior to that with the aldehyde warhead. A co-crystal structure with SARS-CoV-2 3CL protease and a reversibility study indicate that a reversible, thioimidate adduct is formed when the catalytic sulfur forms a covalent bond with the carbon of the nitrile. This effort also identified efflux as a property limiting antiviral activity of these compounds, and together with the positive attributes described these results provide insight for further drug development of novel nitrile peptidomimetics targeting SARS-CoV-2 3CL protease.


  • Organizational Affiliation
    • Li Ka Shing Applied Virology Institute, University of Alberta Edmonton Alberta T6G 2E1 Canada jnieman@ualberta.ca.

Macromolecule Content

  • Total Structure Weight: 68.53 kDa
  • Atom Count: 4,920
  • Modeled Residue Count: 612
  • Deposited Residue Count: 612
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
3C-like proteinase
A, B
306Severe acute respiratory syndrome coronavirus 2Mutation(s): 0
Gene Names: rep1a-1b
EC: 3.4.22.69
UniProt
Find proteins for P0DTD1 (Severe acute respiratory syndrome coronavirus 2)
Explore P0DTD1
Go to UniProtKB:  P0DTD1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0DTD1
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
4IT
(Subject of Investigation/LOI)

Query on 4IT



Download:Ideal Coordinates CCD File
C [auth A],
D [auth B]
N-[(2S)-1-({(1E,2S)-1-imino-3-[(3S)-2-oxopyrrolidin-3-yl]propan-2-yl}amino)-4-methyl-1-oxopentan-2-yl]-4-methoxy-1H-indole-2-carboxamide
C23 H31 N5 O4
FFNRAVWDJXOFBV-NGIQPVBXSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.15 Å
  • R-Value Free:  0.259 (Depositor), 0.288 (DCC)
  • R-Value Work:  0.203 (Depositor)
  • R-Value Observed: 0.206 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 45.46α = 90
b = 53.79β = 101.091
c = 115.46γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XDSdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Canadian Institutes of Health Research (CIHR)CanadaVR3-172655
Natural Sciences and Engineering Research Council (NSERC, Canada)Canada549297-2019

Revision History  (Full details and data files)

  • Version 1.0: 2021-09-01
    Type: Initial release
  • Version 1.1: 2021-12-08
    Changes: Database references
  • Version 1.2: 2023-10-18
    Changes: Data collection, Refinement description
  • Version 1.3: 2024-11-13
    Changes: Structure summary
