Crystal structure of exonuclease ExnV1

Experimental Data Snapshot

  • Resolution: 2.19 Å
  • R-Value Free: 0.278
  • R-Value Work: 0.234
  • R-Value Observed: 0.237

wwPDB Validation   3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history


Crystal structure of DNA polymerase I from Thermus phage G20c.

Ahlqvist, J.Linares-Pasten, J.A.Jasilionis, A.Welin, M.Hakansson, M.Svensson, L.A.Wang, L.Watzlawick, H.Aevarsson, A.Fridjonsson, O.H.Hreggvidsson, G.O.Ketelsen Striberny, B.Glomsaker, E.Lanes, O.Al-Karadaghi, S.Nordberg Karlsson, E.

(2022) Acta Crystallogr D Struct Biol 78: 1384-1398

  • DOI: https://doi.org/10.1107/S2059798322009895
  • Primary Citation of Related Structures:
    7R0K, 7R0T

  • PubMed Abstract:

    This study describes the structure of DNA polymerase I from Thermus phage G20c, termed PolI_G20c. This is the first structure of a DNA polymerase originating from a group of related thermophilic bacteriophages infecting Thermus thermophilus, including phages G20c, TSP4, P74-26, P23-45 and phiFA and the novel phage Tth15-6. Sequence and structural analysis of PolI_G20c revealed a 3'-5' exonuclease domain and a DNA polymerase domain, and activity screening confirmed that both domains were functional. No functional 5'-3' exonuclease domain was present. Structural analysis also revealed a novel specific structure motif, here termed SβαR, that was not previously identified in any polymerase belonging to the DNA polymerases I (or the DNA polymerase A family). The SβαR motif did not show any homology to the sequences or structures of known DNA polymerases. The exception was the sequence conservation of the residues in this motif in putative DNA polymerases encoded in the genomes of a group of thermophilic phages related to Thermus phage G20c. The structure of PolI_G20c was determined with the aid of another structure that was determined in parallel and was used as a model for molecular replacement. This other structure was of a 3'-5' exonuclease termed ExnV1. The cloned and expressed gene encoding ExnV1 was isolated from a thermophilic virus metagenome that was collected from several hot springs in Iceland. The structure of ExnV1, which contains the novel SβαR motif, was first determined to 2.19 Å resolution. With these data at hand, the structure of PolI_G20c was determined to 2.97 Å resolution. The structures of PolI_G20c and ExnV1 are most similar to those of the Klenow fragment of DNA polymerase I (PDB entry 2kzz) from Escherichia coli, DNA polymerase I from Geobacillus stearothermophilus (PDB entry 1knc) and Taq polymerase (PDB entry 1bgx) from Thermus aquaticus.

  • Organizational Affiliation

    Division of Biotechnology, Department of Chemistry, Lund University, PO Box 124, 221 00 Lund, Sweden.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Exonuclease ExnV1318Thermus phage TSP4Mutation(s): 0
Find proteins for A0A411CW45 (Thermus phage TSP4)
Explore A0A411CW45
Go to UniProtKB:  A0A411CW45
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A411CW45
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
TMP (Subject of Investigation/LOI)
Query on TMP

Download Ideal Coordinates CCD File
C10 H15 N2 O8 P
Query on TB

Download Ideal Coordinates CCD File
Query on CL

Download Ideal Coordinates CCD File
F [auth A],
G [auth A],
H [auth A],
I [auth A]
Query on MG

Download Ideal Coordinates CCD File
C [auth A],
D [auth A]
Experimental Data & Validation

Experimental Data

Unit Cell:
Length ( Å )Angle ( ˚ )
a = 42.279α = 90
b = 54.11β = 90
c = 171.732γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
Aimlessdata scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
European Research Council (ERC)European Union685778

Revision History  (Full details and data files)

  • Version 1.0: 2022-11-02
    Type: Initial release
  • Version 1.1: 2022-11-23
    Changes: Database references
