7Q2V | pdb_00007q2v

Crystal structure of the C-terminal catalytic domain of Plasmodium falciparum CTP:phosphocholine cytidylyltransferase with 1-methylpyrrolidin-3-ol

PDB DOI: https://doi.org/10.2210/pdb7Q2V/pdb

Classification: TRANSFERASE
Organism(s): Plasmodium falciparum
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2021-10-26 Released: 2022-11-09
Deposition Author(s): Duclovel, C., Gelin, M., Krimm, I., Cerdan, R., Guichou, J.-F.
Funding Organization(s): Montpellier University of Excellence (MUSE)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.96 Å
R-Value Free:
0.224 (Depositor), 0.226 (DCC)
R-Value Work:
0.192 (Depositor), 0.194 (DCC)
R-Value Observed:
0.194 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7Q2V

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Crystallographic screening using ultra-low-molecular-weight ligands to guide drug design of PfCCT inhibitors

Duclovel, C., Gelin, M., Wein, S., Wengelnik, K., Krimm, I., Guichou, J.F., Cerdan, R.

To be published.

Macromolecule Content

Total Structure Weight: 20.91 kDa
Atom Count: 1,166
Modeled Residue Count: 134
Deposited Residue Count: 180
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Cholinephosphate cytidylyltransferase	A	180	Plasmodium falciparum	Mutation(s): 0 Gene Names: ctP, MAL13P1.86 EC: 2.7.7.15
UniProt
Find proteins for Q8IEE9 (Plasmodium falciparum (isolate 3D7)) Explore Q8IEE9 Go to UniProtKB: Q8IEE9
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8IEE9
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
8PB (Subject of Investigation/LOI) Query on 8PB Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	(3R)-1-methylpyrrolidin-3-ol C₅ H₁₁ N O FLVFPAIGVBQGET-RXMQYKEDSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.96 Å
R-Value Free: 0.224 (Depositor), 0.226 (DCC)
R-Value Work: 0.192 (Depositor), 0.194 (DCC)
R-Value Observed: 0.194 (Depositor)

Space Group: I 2 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 50.268	α = 90
b = 69.182	β = 90
c = 117.724	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data scaling
PDB_EXTRACT	data extraction
PHASER	phasing
XDS	data reduction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2022-11-09

Deposition Author(s):

Funding Organization	Location	Grant Number
Montpellier University of Excellence (MUSE)	France	--

Revision History (Full details and data files)

Version 1.0: 2022-11-09
Type: Initial release
Version 1.1: 2024-01-31
Changes: Data collection, Refinement description
