7Q2K

Crystal structure of the C-terminal catalytic domain of Plasmodium falciparum CTP:phosphocholine cytidylyltransferase with 2-pyrrolidinone

• PDB DOI: https://doi.org/10.2210/pdb7Q2K/pdb

• Classification: TRANSFERASE
• Organism(s): Plasmodium falciparum
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2021-10-25 Released: 2022-11-09
• Deposition Author(s): Duclovel, C., Gelin, M., Krimm, I., Cerdan, R., Guichou, J.-F.
• Funding Organization(s): Montpellier University of Excellence (MUSE)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.94 Å
• R-Value Free: 0.229
• R-Value Work: 0.198
• R-Value Observed: 0.199

Literature

Crystallographic screening using ultra-low-molecular-weight ligands to guide drug design of PfCCT inhibitors.

Duclovel, C., Gelin, M., Wein, S., Wengelnik, K., Krimm, I., Guichou, J.F., Cerdan, R.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 20.9 kDa
• Atom Count: 1,155
• Modelled Residue Count: 133
• Deposited Residue Count: 180
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Cholinephosphate cytidylyltransferase	A	180	Plasmodium falciparum	Mutation(s): 0  Gene Names: ctP, MAL13P1.86 EC: 2.7.7.15
UniProt
Find proteins for Q8IEE9 (Plasmodium falciparum (isolate 3D7)) Explore Q8IEE9  Go to UniProtKB:  Q8IEE9

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
BAQ (Subject of Investigation/LOI)	B [auth A]	pyrrolidin-2-one C4 H7 N O HNJBEVLQSNELDL-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.94 Å
• R-Value Free: 0.229
• R-Value Work: 0.198
• R-Value Observed: 0.199
• Space Group: I 2 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 50.429	α = 90
b = 68.393	β = 90
c = 116.836	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
Aimless	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
PHASER	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2022-11-09
Deposition Author(s): Duclovel, C., Gelin, M., Krimm, I., Cerdan, R., Guichou, J.-F.

---

Funding Organization	Location	Grant Number
Montpellier University of Excellence (MUSE)	France	--

Revision History

• Version 1.0: 2022-11-09
  Type: Initial release

• Version 1.1: 2024-01-31
  Changes: Data collection, Refinement description
