7PPV

Structure of diFe-Sulerythrin at 2.70 MGy total absorbed dose


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.36 Å
  • R-Value Free: 0.199
  • R-Value Work: 0.181
  • R-Value Observed: 0.182

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Determining the oxidation state of elements by X-ray crystallography.

Lennartz, F.Jeoung, J.H.Ruenger, S.Dobbek, H.Weiss, M.S.

(2022) Acta Crystallogr D Struct Biol 78: 238-247

  • DOI: https://doi.org/10.1107/S2059798321013048
  • Primary Citation of Related Structures:
    7PPT, 7PPU, 7PPV

  • PubMed Abstract:

    Protein-mediated redox reactions play a critical role in many biological processes and often occur at centres that contain metal ions as cofactors. In order to understand the exact mechanisms behind these reactions it is important to not only characterize the three-dimensional structures of these proteins and their cofactors, but also to identify the oxidation states of the cofactors involved and to correlate this knowledge with structural information. The only suitable approach for this based on crystallographic measurements is spatially resolved anomalous dispersion (SpReAD) refinement, a method that has been used previously to determine the redox states of metals in iron-sulfur cluster-containing proteins. In this article, the feasibility of this approach for small, non-iron-sulfur redox centres is demonstrated by employing SpReAD analysis to characterize Sulfolobus tokodaii sulerythrin, a ruberythrin-like protein that contains a binuclear metal centre. Differences in oxidation states between the individual iron ions of the binuclear metal centre are revealed in sulerythrin crystals treated with H 2 O 2 . Furthermore, data collection at high X-ray doses leads to photoreduction of this metal centre, showing that careful control of the total absorbed dose is a prerequisite for successfully determining the oxidation state through SpReAD analysis.


  • Organizational Affiliation

    Macromolecular Crystallography, Helmholtz-Zentrum Berlin, Albert-Einstein-Strasse 15, 12489 Berlin, Germany.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Sulerythrin
A, B
144Sulfurisphaera tokodaii str. 7Mutation(s): 0
Gene Names: ST2370STK_23700
UniProt
Find proteins for F9VPE5 (Sulfurisphaera tokodaii (strain DSM 16993 / JCM 10545 / NBRC 100140 / 7))
Explore F9VPE5
Go to UniProtKB:  F9VPE5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupF9VPE5
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
FE (Subject of Investigation/LOI)
Query on FE

Download Ideal Coordinates CCD File
D [auth A],
E [auth A],
I [auth B],
J [auth B]
FE (III) ION
Fe
VTLYFUHAOXGGBS-UHFFFAOYSA-N
CL
Query on CL

Download Ideal Coordinates CCD File
C [auth A],
H [auth B]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
OH (Subject of Investigation/LOI)
Query on OH

Download Ideal Coordinates CCD File
F [auth A],
G [auth B]
HYDROXIDE ION
H O
XLYOFNOQVPJJNP-UHFFFAOYSA-M
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.36 Å
  • R-Value Free: 0.199
  • R-Value Work: 0.181
  • R-Value Observed: 0.182
  • Space Group: P 63
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 72.15α = 90
b = 72.15β = 90
c = 97.98γ = 120
Software Package:
Software NamePurpose
XDSdata reduction
XSCALEdata scaling
PHASERphasing
PHENIXrefinement
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
German Research Foundation (DFG)Germany390540038

Revision History  (Full details and data files)

  • Version 1.0: 2022-06-08
    Type: Initial release
  • Version 1.1: 2024-01-31
    Changes: Data collection, Refinement description
