7P99

Structure of human USPL1 in complex with SUMO2


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free: 0.197
  • R-Value Work: 0.174
  • R-Value Observed: 0.176

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structural basis for the SUMO protease activity of the atypical ubiquitin-specific protease USPL1.

Li, Y.Varejao, N.Reverter, D.

(2022) Nat Commun 13: 1819-1819

  • DOI: https://doi.org/10.1038/s41467-022-29485-0
  • Primary Citation of Related Structures:
    7P99

  • PubMed Abstract:

    Post-translational protein modifications by ubiquitin and ubiquitin-like modifiers regulate many major pathways in the cell. These modifications can be reversed by de-ubiquitinating enzymes such as ubiquitin-specific proteases (USPs). Proteolytic activity towards ubiquitin-modified substrates is common to all USP family members except for USPL1, which shows a unique preference for the ubiquitin-like modifier SUMO. Here, we present the crystal structure of USPL1 bound to SUMO2, defining the key structural elements for the unusual deSUMOylase activity of USPL1. We identify specific contacts between SUMO2 and the USPL1 subdomains, including a unique hydrogen bond network of the SUMO2 C-terminal tail. In addition, we find that USPL1 lacks major structural elements present in all canonical USPs members such as the so-called blocking loops, which facilitates SUMO binding. Our data give insight into how a structural protein scaffold designed to bind ubiquitin has evolved to bind SUMO, providing an example of divergent evolution in the USP family.


  • Organizational Affiliation

    Institut de Biotecnologia i de Biomedicina (IBB) and Dept. de Bioquímica i Biologia Molecular, Universitat Autònoma de Barcelona, 08193, Bellaterra, Spain.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
SUMO-specific isopeptidase USPL1338Homo sapiensMutation(s): 0
Gene Names: USPL1C13orf22D13S106
EC: 3.4.22
UniProt & NIH Common Fund Data Resources
Find proteins for Q5W0Q7 (Homo sapiens)
Explore Q5W0Q7
Go to UniProtKB:  Q5W0Q7
PHAROS:  Q5W0Q7
GTEx:  ENSG00000132952
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5W0Q7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Small ubiquitin-related modifierB [auth C]101Peromyscus maniculatus bairdiiMutation(s): 2
Gene Names: Sumo2
UniProt
Find proteins for A0A6J0CLW1 (Peromyscus maniculatus bairdii)
Explore A0A6J0CLW1
Go to UniProtKB:  A0A6J0CLW1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A6J0CLW1
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download Ideal Coordinates CCD File
C [auth A]ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free: 0.197
  • R-Value Work: 0.174
  • R-Value Observed: 0.176
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 50.709α = 90
b = 69.884β = 90.66
c = 53.643γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
PDB_EXTRACTdata extraction
AutoProcessdata reduction
AutoProcessdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Spanish Ministry of Science, Innovation, and UniversitiesSpain--

Revision History  (Full details and data files)

  • Version 1.0: 2022-03-02
    Type: Initial release
  • Version 1.1: 2022-09-14
    Changes: Database references
  • Version 1.2: 2024-05-01
    Changes: Data collection, Refinement description
