7OQ4

Cryo-EM structure of the ATV RNAP Inhibitory Protein (RIP) bound to the DNA-binding channel of the host's RNA polymerase


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.27 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Structural basis of RNA polymerase inhibition by viral and host factors.

Pilotto, S.Fouqueau, T.Lukoyanova, N.Sheppard, C.Lucas-Staat, S.Diaz-Santin, L.M.Matelska, D.Prangishvili, D.Cheung, A.C.M.Werner, F.

(2021) Nat Commun 12: 5523-5523

  • DOI: https://doi.org/10.1038/s41467-021-25666-5
  • Primary Citation of Related Structures:
    7OK0, 7OQ4, 7OQY

  • PubMed Abstract:
  • RNA polymerase inhibition plays an important role in the regulation of transcription in response to environmental changes and in the virus-host relationship. Here we present the high-resolution structures of two such RNAP-inhibitor complexes that provide the structural bases underlying RNAP inhibition in archaea ...

    RNA polymerase inhibition plays an important role in the regulation of transcription in response to environmental changes and in the virus-host relationship. Here we present the high-resolution structures of two such RNAP-inhibitor complexes that provide the structural bases underlying RNAP inhibition in archaea. The Acidianus two-tailed virus encodes the RIP factor that binds inside the DNA-binding channel of RNAP, inhibiting transcription by occlusion of binding sites for nucleic acid and the transcription initiation factor TFB. Infection with the Sulfolobus Turreted Icosahedral Virus induces the expression of the host factor TFS4, which binds in the RNAP funnel similarly to eukaryotic transcript cleavage factors. However, TFS4 allosterically induces a widening of the DNA-binding channel which disrupts trigger loop and bridge helix motifs. Importantly, the conformational changes induced by TFS4 are closely related to inactivated states of RNAP in other domains of life indicating a deep evolutionary conservation of allosteric RNAP inhibition.


    Organizational Affiliation

    RNAP Laboratory, Institute for Structural and Molecular Biology, University College London, London, UK. f.werner@ucl.ac.uk.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit A'A880Sulfolobus acidocaldarius DSM 639Mutation(s): 0
Gene Names: rpo1NrpoArpoA1Saci_0692
EC: 2.7.7.6
UniProt
Find proteins for P11512 (Sulfolobus acidocaldarius (strain ATCC 33909 / DSM 639 / JCM 8929 / NBRC 15157 / NCIMB 11770))
Explore P11512
Go to UniProtKB:  P11512
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP11512
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit BB1,126Sulfolobus acidocaldarius DSM 639Mutation(s): 1
Gene Names: rpo2rpoBrpoB'Saci_0693
EC: 2.7.7.6
UniProt
Find proteins for P11513 (Sulfolobus acidocaldarius (strain ATCC 33909 / DSM 639 / JCM 8929 / NBRC 15157 / NCIMB 11770))
Explore P11513
Go to UniProtKB:  P11513
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP11513
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit A''C393Sulfolobus acidocaldarius DSM 639Mutation(s): 0
Gene Names: rpo1CrpoA2rpoCSaci_0691
EC: 2.7.7.6
UniProt
Find proteins for P11514 (Sulfolobus acidocaldarius (strain ATCC 33909 / DSM 639 / JCM 8929 / NBRC 15157 / NCIMB 11770))
Explore P11514
Go to UniProtKB:  P11514
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP11514
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit DD264Sulfolobus acidocaldarius DSM 639Mutation(s): 0
Gene Names: rpo3rpoDSaci_0083
EC: 2.7.7.6
UniProt
Find proteins for P39471 (Sulfolobus acidocaldarius (strain ATCC 33909 / DSM 639 / JCM 8929 / NBRC 15157 / NCIMB 11770))
Explore P39471
Go to UniProtKB:  P39471
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP39471
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChainsSequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit EE183Sulfolobus acidocaldarius DSM 639Mutation(s): 0
Gene Names: rpo7rpoESaci_0834
EC: 2.7.7.6
UniProt
Find proteins for P39466 (Sulfolobus acidocaldarius (strain ATCC 33909 / DSM 639 / JCM 8929 / NBRC 15157 / NCIMB 11770))
Explore P39466
Go to UniProtKB:  P39466
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP39466
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChainsSequence LengthOrganismDetailsImage
DNA-directed RNA polymerase, subunit FF114Sulfolobus acidocaldarius DSM 639Mutation(s): 0
Gene Names: rpo4rpoFSaci_0625
EC: 2.7.7.6
UniProt
Find proteins for Q4JB12 (Sulfolobus acidocaldarius (strain ATCC 33909 / DSM 639 / JCM 8929 / NBRC 15157 / NCIMB 11770))
Explore Q4JB12
Go to UniProtKB:  Q4JB12
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ4JB12
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChainsSequence LengthOrganismDetailsImage
DNA-directed RNA polymerase, subunit GG130Sulfolobus acidocaldarius DSM 639Mutation(s): 0
Gene Names: rpoGSaci_0661rpo8
EC: 2.7.7.6
UniProt
Find proteins for Q4JAY4 (Sulfolobus acidocaldarius (strain ATCC 33909 / DSM 639 / JCM 8929 / NBRC 15157 / NCIMB 11770))
Explore Q4JAY4
Go to UniProtKB:  Q4JAY4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ4JAY4
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChainsSequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit HH84Sulfolobus acidocaldarius DSM 639Mutation(s): 0
Gene Names: rpo5rpoB''rpoHSaci_0694
EC: 2.7.7.6
UniProt
Find proteins for P11521 (Sulfolobus acidocaldarius (strain ATCC 33909 / DSM 639 / JCM 8929 / NBRC 15157 / NCIMB 11770))
Explore P11521
Go to UniProtKB:  P11521
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP11521
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChainsSequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit KI [auth K]89Sulfolobus acidocaldarius DSM 639Mutation(s): 0
Gene Names: rpo6rpoKSaci_1370
EC: 2.7.7.6
UniProt
Find proteins for P39463 (Sulfolobus acidocaldarius (strain ATCC 33909 / DSM 639 / JCM 8929 / NBRC 15157 / NCIMB 11770))
Explore P39463
Go to UniProtKB:  P39463
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP39463
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChainsSequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit LJ [auth L]90Sulfolobus acidocaldarius DSM 639Mutation(s): 0
Gene Names: rpo11rpoLSaci_0173
EC: 2.7.7.6
UniProt
Find proteins for P46217 (Sulfolobus acidocaldarius (strain ATCC 33909 / DSM 639 / JCM 8929 / NBRC 15157 / NCIMB 11770))
Explore P46217
Go to UniProtKB:  P46217
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP46217
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChainsSequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit NK [auth N]66Sulfolobus acidocaldarius DSM 639Mutation(s): 0
Gene Names: rpo10rpoNSaci_0087
EC: 2.7.7.6
UniProt
Find proteins for P39472 (Sulfolobus acidocaldarius (strain ATCC 33909 / DSM 639 / JCM 8929 / NBRC 15157 / NCIMB 11770))
Explore P39472
Go to UniProtKB:  P39472
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP39472
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChainsSequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit PL [auth P]48Sulfolobus acidocaldarius DSM 639Mutation(s): 0
Gene Names: rpo12rpoPSaci_0864
EC: 2.7.7.6
UniProt
Find proteins for Q4JAE8 (Sulfolobus acidocaldarius (strain ATCC 33909 / DSM 639 / JCM 8929 / NBRC 15157 / NCIMB 11770))
Explore Q4JAE8
Go to UniProtKB:  Q4JAE8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ4JAE8
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 13
MoleculeChainsSequence LengthOrganismDetailsImage
Conserved proteinM [auth Q]105Sulfolobus acidocaldarius DSM 639Mutation(s): 0
Gene Names: rpo13Saci_0816
EC: 2.7.7.6
UniProt
Find proteins for Q4JAJ6 (Sulfolobus acidocaldarius (strain ATCC 33909 / DSM 639 / JCM 8929 / NBRC 15157 / NCIMB 11770))
Explore Q4JAJ6
Go to UniProtKB:  Q4JAJ6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ4JAJ6
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 14
MoleculeChainsSequence LengthOrganismDetailsImage
RNAP inhibitory proteinN [auth Z]149Acidianus two-tailed virusMutation(s): 0
UniProt
Find proteins for Q3V4R7 (Acidianus two-tailed virus)
Explore Q3V4R7
Go to UniProtKB:  Q3V4R7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ3V4R7
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.27 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION3.0
MODEL REFINEMENTPHENIX1.19

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Wellcome TrustUnited Kingdom207446/Z/17/Z

Revision History  (Full details and data files)

  • Version 1.0: 2021-08-25
    Type: Initial release
  • Version 1.1: 2021-10-13
    Changes: Data collection, Database references
