7OC3

Crystal structure of the third tudor domain of Qin

PDB DOI: https://doi.org/10.2210/pdb7OC3/pdb

Classification: PROTEIN BINDING
Organism(s): Drosophila melanogaster
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2021-04-25 Released: 2022-05-04
Deposition Author(s): Dhimole, N., Klug, W., Carlomagno, T.
Funding Organization(s): German Research Foundation

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.25 Å
R-Value Free: 0.245
R-Value Work: 0.208
R-Value Observed: 0.210

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Crystal structure of the third tudor domain of Qin

Dhimole, N., Klug, W., Carlomagno, T.

To be published.

Macromolecule Content

Total Structure Weight: 48.49 kDa
Atom Count: 3,314
Modelled Residue Count: 421
Deposited Residue Count: 424
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Qin	A, B	212	Drosophila melanogaster	Mutation(s): 0 Gene Names: qin, CG14303, CG14306, Dmel\CG43726, kumo, Qin, CG43726, Dmel_CG43726
UniProt
Find proteins for Q9VE55 (Drosophila melanogaster) Explore Q9VE55 Go to UniProtKB: Q9VE55
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q9VE55
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PO4 Query on PO4 Download Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A]	C [auth A]	PHOSPHATE ION O₄ P NBIIXXVUZAFLBC-UHFFFAOYSA-K		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.25 Å
R-Value Free: 0.245
R-Value Work: 0.208
R-Value Observed: 0.210
Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 74.8	α = 90
b = 74.8	β = 90
c = 165.092	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
SCALA	data scaling
PHENIX	phasing

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2022-05-04

Deposition Author(s):

Funding Organization	Location	Grant Number
German Research Foundation	Germany	CA 294

Revision History (Full details and data files)

Version 1.0: 2022-05-04
Type: Initial release
