7O5Y

PilA minor pilin of Streptococcus sanguinis type IV pili


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.77 Å
  • R-Value Free: 0.238
  • R-Value Work: 0.206

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Characterization of a glycan-binding complex of minor pilins completes the analysis of Streptococcus sanguinis type 4 pili subunits.

Shahin, M.Sheppard, D.Raynaud, C.Berry, J.L.Gurung, I.Silva, L.M.Feizi, T.Liu, Y.Pelicic, V.

(2023) Proc Natl Acad Sci U S A 120: e2216237120-e2216237120

  • DOI: https://doi.org/10.1073/pnas.2216237120
  • Primary Citation of Related Structures:
    7O5Y, 7OA7, 7OA8

  • PubMed Abstract:

    Type 4 filaments (T4F)-of which type 4 pili (T4P) are the archetype-are a superfamily of nanomachines nearly ubiquitous in prokaryotes. T4F are polymers of one major pilin, which also contain minor pilins whose roles are often poorly understood. Here, we complete the structure/function analysis of the full set of T4P pilins in the opportunistic bacterial pathogen Streptococcus sanguinis . We determined the structure of the minor pilin PilA, which is unexpectedly similar to one of the subunits of a tip-located complex of four minor pilins, widely conserved in T4F. We found that PilA interacts and dramatically stabilizes the minor pilin PilC. We determined the structure of PilC, showing that it is a modular pilin with a lectin module binding a subset of glycans prevalent in the human glycome, the host of S. sanguinis . Altogether, our findings support a model whereby the minor pilins in S. sanguinis T4P form a tip-located complex promoting adhesion to various host receptors. This has general implications for T4F.


  • Organizational Affiliation

    Medical Research Council Centre for Molecular Bacteriology and Infection, Imperial College London, SW7 2AZ London, United Kingdom.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Type IV pilus biogenesis protein PilAA [auth B],
B [auth C],
C [auth D],
D [auth A]
140Streptococcus sanguinisMutation(s): 0
Gene Names: pilASSV_2239
UniProt
Find proteins for A0A0B7GNW3 (Streptococcus sanguinis)
Explore A0A0B7GNW3
Go to UniProtKB:  A0A0B7GNW3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0B7GNW3
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A [auth B],
B [auth C],
C [auth D],
D [auth A]
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.77 Å
  • R-Value Free: 0.238
  • R-Value Work: 0.206
  • Space Group: P 43 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 93.32α = 90
b = 93.32β = 90
c = 181.13γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
xia2data reduction
xia2data scaling
CRANK2phasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Medical Research Council (MRC, United Kingdom)United KingdomMR/P022197/1

Revision History  (Full details and data files)

  • Version 1.0: 2022-04-20
    Type: Initial release
  • Version 1.1: 2023-01-18
    Changes: Database references
  • Version 1.2: 2023-01-25
    Changes: Database references
