7NYW

Cryo-EM structure of the MukBEF-MatP-DNA head module


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.10 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Cryo-EM structure of MukBEF reveals DNA loop entrapment at chromosomal unloading sites.

Burmann, F.Funke, L.F.H.Chin, J.W.Lowe, J.

(2021) Mol Cell 81: 4891-4906.e8

  • DOI: 10.1016/j.molcel.2021.10.011
  • Primary Citation of Related Structures:
    7NYW, 7NYX, 7NYY, 7NYZ, 7NZ0, 7NZ2, 7NZ3, 7NZ4

  • PubMed Abstract:
  • The ring-like structural maintenance of chromosomes (SMC) complex MukBEF folds the genome of Escherichia coli and related bacteria into large loops, presumably by active DNA loop extrusion. MukBEF activity within the replication terminus macrodomain is suppressed by the sequence-specific unloader MatP ...

    The ring-like structural maintenance of chromosomes (SMC) complex MukBEF folds the genome of Escherichia coli and related bacteria into large loops, presumably by active DNA loop extrusion. MukBEF activity within the replication terminus macrodomain is suppressed by the sequence-specific unloader MatP. Here, we present the complete atomic structure of MukBEF in complex with MatP and DNA as determined by electron cryomicroscopy (cryo-EM). The complex binds two distinct DNA double helices corresponding to the arms of a plectonemic loop. MatP-bound DNA threads through the MukBEF ring, while the second DNA is clamped by the kleisin MukF, MukE, and the MukB ATPase heads. Combinatorial cysteine cross-linking confirms this topology of DNA loop entrapment in vivo. Our findings illuminate how a class of near-ubiquitous DNA organizers with important roles in genome maintenance interacts with the bacterial chromosome.


    Related Citations:
    • DNA entrapment revealed by the structure of bacterial condensin MukBEF
      Buermann, F., Funke, L.F.H., Chin, J.W., Lowe, J.
      (2021) Biorxiv --: --

    Organizational Affiliation

    MRC Laboratory of Molecular Biology, Structural Studies Division, Cambridge Biomedical Campus, Cambridge, UK. Electronic address: jyl@mrc-lmb.cam.ac.uk.



Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Chromosome partition protein MukBA, B1,482Photorhabdus thracensisMutation(s): 1
Gene Names: mukBVY86_15870
UniProt
Find proteins for A0A0F7LRY2 (Photorhabdus thracensis)
Explore A0A0F7LRY2
Go to UniProtKB:  A0A0F7LRY2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0F7LRY2
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Chromosome partition protein MukFC, D440Photorhabdus thracensisMutation(s): 0
Gene Names: mukFVY86_15860
UniProt
Find proteins for A0A0F7LMQ4 (Photorhabdus thracensis)
Explore A0A0F7LMQ4
Go to UniProtKB:  A0A0F7LMQ4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0F7LMQ4
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
Chromosome partition protein MukEE, F240Photorhabdus thracensisMutation(s): 0
Gene Names: mukEVY86_15865
UniProt
Find proteins for A0A0F7LPV6 (Photorhabdus thracensis)
Explore A0A0F7LPV6
Go to UniProtKB:  A0A0F7LPV6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0F7LPV6
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetailsImage
Acyl carrier proteinG, H78Escherichia coli BL21(DE3)Mutation(s): 0
UniProt
Find proteins for P0A6A8 (Escherichia coli (strain K12))
Explore P0A6A8
Go to UniProtKB:  P0A6A8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A6A8
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChainsSequence LengthOrganismDetailsImage
Macrodomain Ter proteinI, J151Photorhabdus thracensisMutation(s): 0
Gene Names: matPVY86_22090
UniProt
Find proteins for A0A0F7LUV5 (Photorhabdus thracensis)
Explore A0A0F7LUV5
Go to UniProtKB:  A0A0F7LUV5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0F7LUV5
Protein Feature View
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChainsLengthOrganismImage
matS2 DNA 80 b, oligo FBA769K80Photorhabdus thracensis
Protein Feature View
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChainsLengthOrganismImage
matS2 DNA 80 b, oligo FBA770L80Photorhabdus thracensis
Protein Feature View
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChainsLengthOrganismImage
DNA 80 bM, N30Photorhabdus thracensis
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ATP
Query on ATP

Download Ideal Coordinates CCD File
P [auth A],
R [auth B]
ADENOSINE-5'-TRIPHOSPHATE
C10 H16 N5 O13 P3
ZKHQWZAMYRWXGA-KQYNXXCUSA-N
 Ligand Interaction
PNS
Query on PNS

Download Ideal Coordinates CCD File
S [auth G],
T [auth H]
4'-PHOSPHOPANTETHEINE
C11 H23 N2 O7 P S
JDMUPRLRUUMCTL-VIFPVBQESA-N
 Ligand Interaction
MG
Query on MG

Download Ideal Coordinates CCD File
O [auth A],
Q [auth B]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.10 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2021-07-07
    Type: Initial release
  • Version 1.1: 2022-03-23
    Changes: Database references, Source and taxonomy, Structure summary
