7NPQ

Crystal structure of the human LL37(17-29) I24C mutant antimicrobial peptide


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.50 Å
  • R-Value Free: 0.192
  • R-Value Work: 0.179
  • R-Value Observed: 0.180

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Rare by Natural Selection: Disulfide-Bonded Supramolecular Antimicrobial Peptides.

Engelberg, Y.Ragonis-Bachar, P.Landau, M.

(2022) Biomacromolecules 23: 926-936

  • DOI: https://doi.org/10.1021/acs.biomac.1c01353
  • Primary Citation of Related Structures:
    7NPQ

  • PubMed Abstract:

    Human LL-37 17-29 is an antimicrobial peptide forming thermostable supramolecular fibrils that surround bacterial cells. The crystal structure of LL-37 17-29 bearing an I24C substitution of most buried position in the fibril revealed disulfide-bonded dimers that further assembled into a fibrillar structure of densely packed helices . We further demonstrated the position-dependent controllable antibacterial activity of LL-37 17-29 I24C and other cysteine mutants, mediated by regulation of intermolecular disulfide bonds and their role in the formation of supramolecular structures. The morphology of the fibrils and their antibacterial mechanism of action might be dependent on their interactions with specific bacteria. The significant effect of disulfide bonds on the assembly into supramolecular structures and their sensitivity to reducing/oxidizing conditions may explain why short helical antimicrobial peptides with a single cysteine and an odd number of cysteines are selected against in nature.


  • Organizational Affiliation

    Department of Biology, Technion-Israel Institute of Technology, Haifa 3200003, Israel.


Macromolecules

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Cathelicidin antimicrobial peptide
A, B
13Homo sapiensMutation(s): 1
Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for P49913 (Homo sapiens)
Explore P49913
Go to UniProtKB:  P49913
PHAROS:  P49913
GTEx:  ENSG00000164047
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP49913
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.50 Å
  • R-Value Free: 0.192
  • R-Value Work: 0.179
  • R-Value Observed: 0.180
  • Space Group: P 41 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 34.92α = 90
b = 34.92β = 90
c = 44.57γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
XSCALEdata scaling
PHASERphasing
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2022-02-16
    Type: Initial release
  • Version 1.1: 2022-03-23
    Changes: Database references
  • Version 1.2: 2024-01-31
    Changes: Data collection, Refinement description
