7NMJ

Crystal structure of Polyphosphate Kinase 2 from Deinococcus radiodurans in complex with ADP

PDB DOI: https://doi.org/10.2210/pdb7NMJ/pdb

Classification: TRANSFERASE
Organism(s): Deinococcus radiodurans R1 = ATCC 13939 = DSM 20539
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2021-02-23 Released: 2021-04-07
Deposition Author(s): Silva, S.T.N., Romao, C.
Funding Organization(s): Fundacao para a Ciencia e a Tecnologia

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.08 Å
R-Value Free: 0.248
R-Value Work: 0.187
R-Value Observed: 0.190

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

Crystal structure of Polyphosphate Kinase 2 from Deinococcus radiodurans in complex with ADP

Silva, S.T.N., Romao, C.

To be published.

Macromolecule Content

Total Structure Weight: 125.06 kDa
Atom Count: 9,148
Modelled Residue Count: 1,064
Deposited Residue Count: 1,064
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
PPK2 domain-containing protein	A, B, C, D	266	Deinococcus radiodurans R1 = ATCC 13939 = DSM 20539	Mutation(s): 0 Gene Names: DR_0132
UniProt
Find proteins for Q9RY20 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / CCUG 27074 / LMG 4051 / NBRC 15346 / NCIMB 9279 / VKM B-1422 / R1)) Explore Q9RY20 Go to UniProtKB: Q9RY20
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q9RY20
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ADP (Subject of Investigation/LOI) Query on ADP Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth B] SDF format, chain J [auth C] SDF format, chain K [auth C] SDF format, chain L [auth D] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth B] MOL2 format, chain J [auth C] MOL2 format, chain K [auth C] MOL2 format, chain L [auth D]	E [auth A] F [auth A] G [auth B] J [auth C] K [auth C] E [auth A], F [auth A], G [auth B], J [auth C], K [auth C], L [auth D]	ADENOSINE-5'-DIPHOSPHATE C₁₀ H₁₅ N₅ O₁₀ P₂ XTWYTFMLZFPYCI-KQYNXXCUSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth B] Focus chain J [auth C] Focus chain K [auth C] Focus chain L [auth D] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth B] Focus chain J [auth C] Focus chain K [auth C] Focus chain L [auth D]
PO4 (Subject of Investigation/LOI) Query on PO4 Download Ideal Coordinates CCD File SDF format, chain M [auth D] MOL2 format, chain M [auth D]	M [auth D]	PHOSPHATE ION O₄ P NBIIXXVUZAFLBC-UHFFFAOYSA-K		Interactions Focus chain M [auth D] Interactions & Density Focus chain M [auth D]
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain H [auth B] SDF format, chain I [auth B] MOL2 format, chain H [auth B] MOL2 format, chain I [auth B]	H [auth B], I [auth B]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain H [auth B] Focus chain I [auth B] Interactions & Density Focus chain H [auth B] Focus chain I [auth B]
MG (Subject of Investigation/LOI) Query on MG Download Ideal Coordinates CCD File SDF format, chain N [auth D] MOL2 format, chain N [auth D]	N [auth D]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain N [auth D] Interactions & Density Focus chain N [auth D]
