7MWM | pdb_00007mwm

Crystal structure of MBD2 with DNA

PDB DOI: https://doi.org/10.2210/pdb7MWM/pdb
NAKB: 7MWM

Classification: DNA BINDING PROTEIN/DNA
Organism(s): Homo sapiens, synthetic construct
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2021-05-17 Released: 2021-07-07
Deposition Author(s): Liu, K., Dong, A., Edwards, A.M., Arrowsmith, C.H., Min, J., Structural Genomics Consortium (SGC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free:
0.206 (Depositor), 0.210 (DCC)
R-Value Work:
0.186 (Depositor), 0.200 (DCC)
R-Value Observed:
0.187 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of MBD2 with DNA

Liu, K., Dong, A., Edwards, A.M., Arrowsmith, C.H., Min, J., Structural Genomics Consortium (SGC)

To be published.

Macromolecule Content

Total Structure Weight: 32.24 kDa
Atom Count: 2,469
Modelled Residue Count: 196
Deposited Residue Count: 206
Unique protein chains: 1
Unique nucleic acid chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Methyl-CpG-binding domain protein 2	A, B	79	Homo sapiens	Mutation(s): 0 Gene Names: MBD2
UniProt & NIH Common Fund Data Resources
Find proteins for Q9UBB5 (Homo sapiens) Explore Q9UBB5 Go to UniProtKB: Q9UBB5
PHAROS: Q9UBB5 GTEx: ENSG00000134046
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q9UBB5
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence | 3D Structure

Entity ID: 2
Molecule	Chains	Length	Organism	Image
DNA (5'-D(GPCPCPAPA)-R(P(5MC))-D(PGPTPTPGPGPC)-3')	C, D, E, F	12	synthetic construct
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
UNX Query on UNX Download Ideal Coordinates CCD File SDF format, chain AA [auth B] SDF format, chain BA [auth B] SDF format, chain CA [auth B] SDF format, chain DA [auth B] SDF format, chain EA [auth C] SDF format, chain FA [auth C] SDF format, chain G [auth A] SDF format, chain GA [auth D] SDF format, chain H [auth A] SDF format, chain HA [auth D] SDF format, chain I [auth A] SDF format, chain IA [auth D] SDF format, chain J [auth A] SDF format, chain JA [auth E] SDF format, chain K [auth A] SDF format, chain KA [auth E] SDF format, chain L [auth A] SDF format, chain LA [auth E] SDF format, chain M [auth A] SDF format, chain MA [auth F] SDF format, chain N [auth A] SDF format, chain NA [auth F] SDF format, chain O [auth A] SDF format, chain OA [auth F] SDF format, chain P [auth A] SDF format, chain Q [auth A] SDF format, chain R [auth A] SDF format, chain S [auth B] SDF format, chain T [auth B] SDF format, chain U [auth B] SDF format, chain V [auth B] SDF format, chain W [auth B] SDF format, chain X [auth B] SDF format, chain Y [auth B] SDF format, chain Z [auth B] MOL2 format, chain AA [auth B] MOL2 format, chain BA [auth B] MOL2 format, chain CA [auth B] MOL2 format, chain DA [auth B] MOL2 format, chain EA [auth C] MOL2 format, chain FA [auth C] MOL2 format, chain G [auth A] MOL2 format, chain GA [auth D] MOL2 format, chain H [auth A] MOL2 format, chain HA [auth D] MOL2 format, chain I [auth A] MOL2 format, chain IA [auth D] MOL2 format, chain J [auth A] MOL2 format, chain JA [auth E] MOL2 format, chain K [auth A] MOL2 format, chain KA [auth E] MOL2 format, chain L [auth A] MOL2 format, chain LA [auth E] MOL2 format, chain M [auth A] MOL2 format, chain MA [auth F] MOL2 format, chain N [auth A] MOL2 format, chain NA [auth F] MOL2 format, chain O [auth A] MOL2 format, chain OA [auth F] MOL2 format, chain P [auth A] MOL2 format, chain Q [auth A] MOL2 format, chain R [auth A] MOL2 format, chain S [auth B] MOL2 format, chain T [auth B] MOL2 format, chain U [auth B] MOL2 format, chain V [auth B] MOL2 format, chain W [auth B] MOL2 format, chain X [auth B] MOL2 format, chain Y [auth B] MOL2 format, chain Z [auth B] mmCIF format, chain AA [auth B] mmCIF format, chain BA [auth B] mmCIF format, chain CA [auth B] mmCIF format, chain DA [auth B] mmCIF format, chain EA [auth C] mmCIF format, chain FA [auth C] mmCIF format, chain G [auth A] mmCIF format, chain GA [auth D] mmCIF format, chain H [auth A] mmCIF format, chain HA [auth D] mmCIF format, chain I [auth A] mmCIF format, chain IA [auth D] mmCIF format, chain J [auth A] mmCIF format, chain JA [auth E] mmCIF format, chain K [auth A] mmCIF format, chain KA [auth E] mmCIF format, chain L [auth A] mmCIF format, chain LA [auth E] mmCIF format, chain M [auth A] mmCIF format, chain MA [auth F] mmCIF format, chain N [auth A] mmCIF format, chain NA [auth F] mmCIF format, chain O [auth A] mmCIF format, chain OA [auth F] mmCIF format, chain P [auth A] mmCIF format, chain Q [auth A] mmCIF format, chain R [auth A] mmCIF format, chain S [auth B] mmCIF format, chain T [auth B] mmCIF format, chain U [auth B] mmCIF format, chain V [auth B] mmCIF format, chain W [auth B] mmCIF format, chain X [auth B] mmCIF format, chain Y [auth B] mmCIF format, chain Z [auth B]	AA [auth B] BA [auth B] CA [auth B] DA [auth B] EA [auth C] AA [auth B], BA [auth B], CA [auth B], DA [auth B], EA [auth C], FA [auth C], G [auth A], GA [auth D], H [auth A], HA [auth D], I [auth A], IA [auth D], J [auth A], JA [auth E], K [auth A], KA [auth E], L [auth A], LA [auth E], M [auth A], MA [auth F], N [auth A], NA [auth F], O [auth A], OA [auth F], P [auth A], Q [auth A], R [auth A], S [auth B], T [auth B], U [auth B], V [auth B], W [auth B], X [auth B], Y [auth B], Z [auth B]	UNKNOWN ATOM OR ION X		Interactions Focus chain AA [auth B] Focus chain BA [auth B] Focus chain CA [auth B] Focus chain DA [auth B] Focus chain EA [auth C] Focus chain FA [auth C] Focus chain G [auth A] Focus chain GA [auth D] Focus chain H [auth A] Focus chain HA [auth D] Focus chain I [auth A] Focus chain IA [auth D] Focus chain J [auth A] Focus chain JA [auth E] Focus chain K [auth A] Focus chain KA [auth E] Focus chain L [auth A] Focus chain LA [auth E] Focus chain M [auth A] Focus chain MA [auth F] Focus chain N [auth A] Focus chain NA [auth F] Focus chain O [auth A] Focus chain OA [auth F] Focus chain P [auth A] Focus chain Q [auth A] Focus chain R [auth A] Focus chain S [auth B] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B] Interactions & Density Focus chain AA [auth B] Focus chain BA [auth B] Focus chain CA [auth B] Focus chain DA [auth B] Focus chain EA [auth C] Focus chain FA [auth C] Focus chain G [auth A] Focus chain GA [auth D] Focus chain H [auth A] Focus chain HA [auth D] Focus chain I [auth A] Focus chain IA [auth D] Focus chain J [auth A] Focus chain JA [auth E] Focus chain K [auth A] Focus chain KA [auth E] Focus chain L [auth A] Focus chain LA [auth E] Focus chain M [auth A] Focus chain MA [auth F] Focus chain N [auth A] Focus chain NA [auth F] Focus chain O [auth A] Focus chain OA [auth F] Focus chain P [auth A] Focus chain Q [auth A] Focus chain R [auth A] Focus chain S [auth B] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B]
