7MMP | pdb_00007mmp

Crystal Structure of the Class Ie Ribonucleotide Reductase

PDB DOI: https://doi.org/10.2210/pdb7MMP/pdb

Classification: OXIDOREDUCTASE
Organism(s): Aerococcus sp. Group 1, Aerococcus urinae
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2021-04-30 Released: 2022-05-04
Deposition Author(s): Palowitch, G.M., Boal, A.K.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.15 Å
R-Value Free:
0.224 (Depositor), 0.230 (DCC)
R-Value Work:
0.195 (Depositor), 0.200 (DCC)
R-Value Observed:
0.196 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Ribonucleotide Reductase

Palowitch, G.M., Boal, A.K.

To be published.

Macromolecule Content

Total Structure Weight: 225.26 kDa
Atom Count: 15,134
Modeled Residue Count: 1,798
Deposited Residue Count: 1,956
Unique protein chains: 2

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Ribonucleoside-diphosphate reductase	A, B, C, D	342	Aerococcus sp. Group 1	Mutation(s): 0 Gene Names: HMPREF9243_0731 EC: 1.17.4.1
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Protein NrdI	E, F [auth G], G [auth F], H	147	Aerococcus urinae	Mutation(s): 0 Gene Names: nrdI, CYJ29_07405, DBT54_07500
UniProt
Find proteins for A0A178HGH7 (Aerococcus urinae) Explore A0A178HGH7 Go to UniProtKB: A0A178HGH7
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A178HGH7
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
FMN (Subject of Investigation/LOI) Query on FMN Download Ideal Coordinates CCD File SDF format, chain K [auth E] SDF format, chain L [auth G] SDF format, chain N [auth F] SDF format, chain P [auth H] MOL2 format, chain K [auth E] MOL2 format, chain L [auth G] MOL2 format, chain N [auth F] MOL2 format, chain P [auth H] mmCIF format, chain K [auth E] mmCIF format, chain L [auth G] mmCIF format, chain N [auth F] mmCIF format, chain P [auth H]	K [auth E], L [auth G], N [auth F], P [auth H]	FLAVIN MONONUCLEOTIDE C₁₇ H₂₁ N₄ O₉ P FVTCRASFADXXNN-SCRDCRAPSA-N		Interactions Focus chain K [auth E] Focus chain L [auth G] Focus chain N [auth F] Focus chain P [auth H] Interactions & Density Focus chain K [auth E] Focus chain L [auth G] Focus chain N [auth F] Focus chain P [auth H]
CA Query on CA Download Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain J [auth C] SDF format, chain M [auth G] SDF format, chain O [auth F] SDF format, chain Q [auth H] MOL2 format, chain I [auth A] MOL2 format, chain J [auth C] MOL2 format, chain M [auth G] MOL2 format, chain O [auth F] MOL2 format, chain Q [auth H] mmCIF format, chain I [auth A] mmCIF format, chain J [auth C] mmCIF format, chain M [auth G] mmCIF format, chain O [auth F] mmCIF format, chain Q [auth H]	I [auth A], J [auth C], M [auth G], O [auth F], Q [auth H]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain I [auth A] Focus chain J [auth C] Focus chain M [auth G] Focus chain O [auth F] Focus chain Q [auth H] Interactions & Density Focus chain I [auth A] Focus chain J [auth C] Focus chain M [auth G] Focus chain O [auth F] Focus chain Q [auth H]
