7MHD | pdb_00007mhd

Thioesterase Domain of Human Fatty Acid Synthase (FASN-TE) binding a competitive inhibitor SBP-7635

PDB DOI: https://doi.org/10.2210/pdb7MHD/pdb

Classification: Hydrolase/Inhibitor
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2021-04-15 Released: 2022-04-20
Deposition Author(s): Aleshin, A.E., Lambert, L., Liddington, R.C., Cosford, N.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.03 Å
R-Value Free:
0.246 (Depositor), 0.250 (DCC)
R-Value Work:
0.193 (Depositor), 0.200 (DCC)
R-Value Observed:
0.196 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Thioesterase Domain of Human Fatty Acid Synthase (FASN-TE) binding a competitive inhibitor SBP-7635

Aleshin, A.E., Lambert, L., Liddington, R.C., Cosford, N.

To be published.

Macromolecule Content

Total Structure Weight: 32.93 kDa
Atom Count: 2,374
Modeled Residue Count: 282
Deposited Residue Count: 298
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Fatty acid synthase	A	298	Homo sapiens	Mutation(s): 0 Gene Names: FASN, FAS EC: 3.1.2.14 (PDB Primary Data), 2.3.1.85 (UniProt), 2.3.1.41 (UniProt), 1.3.1.39 (UniProt), 2.3.1.38 (UniProt), 4.2.1.59 (UniProt), 1.1.1.100 (UniProt), 2.3.1.39 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for P49327 (Homo sapiens) Explore P49327 Go to UniProtKB: P49327
PHAROS: P49327 GTEx: ENSG00000169710
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P49327
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ZEP (Subject of Investigation/LOI) Query on ZEP Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	N,N-diethyl-4-{2-[(2-fluorophenyl)methyl]-1,3-thiazol-4-yl}benzene-1-sulfonamide C₂₀ H₂₁ F N₂ O₂ S₂ PZNJPNGENGJLBG-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.03 Å
R-Value Free: 0.246 (Depositor), 0.250 (DCC)
R-Value Work: 0.193 (Depositor), 0.200 (DCC)
R-Value Observed: 0.196 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 53.886	α = 90
b = 61.486	β = 90
c = 77.45	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Released Date: 2022-04-20

Deposition Author(s):

Liddington, R.C.

Revision History (Full details and data files)

Version 1.0: 2022-04-20
Type: Initial release
Version 1.1: 2023-10-18
Changes: Data collection, Refinement description
