7MAI | pdb_00007mai

HIV-1 Protease (I84V) in Complex with PU5 (LR4-47)

PDB DOI: https://doi.org/10.2210/pdb7MAI/pdb

Classification: HYDROLASE/HYDROLASE INHIBITOR
Organism(s): Human immunodeficiency virus 1
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2021-03-31 Released: 2022-04-06
Deposition Author(s): Lockbaum, G.J., Schiffer, C.A.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.79 Å
R-Value Free:
0.241 (Depositor), 0.240 (DCC)
R-Value Work:
0.198 (Depositor), 0.200 (DCC)
R-Value Observed:
0.200 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

HIV-1 Protease (I84V) in Complex with PU5 (LR4-47)

Lockbaum, G.J., Schiffer, C.A.

To be published.

Macromolecule Content

Total Structure Weight: 22.41 kDa
Atom Count: 1,585
Modeled Residue Count: 198
Deposited Residue Count: 198
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Protease	A [auth B], B [auth A]	99	Human immunodeficiency virus 1	Mutation(s): 1 Gene Names: gag-pol EC: 3.4.23.16
UniProt
Find proteins for P12497 (Human immunodeficiency virus type 1 group M subtype B (isolate NY5)) Explore P12497 Go to UniProtKB: P12497
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P12497
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
XVJ (Subject of Investigation/LOI) Query on XVJ Download Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	diethyl [(4-{(2S,3R)-4-{[(1,3-benzothiazol-6-yl)sulfonyl][(2S)-2-methylbutyl]amino}-2-[({[(3R,3aS,6aR)-hexahydrofuro[2,3-b]furan-3-yl]oxy}carbonyl)amino]-3-hydroxybutyl}phenoxy)methyl]phosphonate C₃₄ H₄₈ N₃ O₁₁ P S₂ PKQJSHMJDBCIKD-GJOHHWMHSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.79 Å
R-Value Free: 0.241 (Depositor), 0.240 (DCC)
R-Value Work: 0.198 (Depositor), 0.200 (DCC)
R-Value Observed: 0.200 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 51.051	α = 90
b = 58.091	β = 90
c = 61.802	γ = 90

Software Package:

Software Name	Purpose
XSCALE	data scaling
PHASER	phasing
PHENIX	refinement
Coot	model building
PDB_EXTRACT	data extraction
XDS	data reduction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History & Funding Information

Deposition Data

Released Date: 2022-04-06

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	P01-GM109767

Revision History (Full details and data files)

Version 1.0: 2022-04-06
Type: Initial release
Version 1.1: 2023-10-18
Changes: Data collection, Refinement description
