7LQP | pdb_00007lqp

Rapid development of potent inhibitors of the HIV integrase-LEDGF interaction by fragment-linking using off-rate screening

PDB DOI: https://doi.org/10.2210/pdb7LQP/pdb

Classification: TRANSFERASE/INHIBITOR
Organism(s): Human immunodeficiency virus 1
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2021-02-15 Released: 2022-02-23
Deposition Author(s): Gorman, M.A., Parker, M.W.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.07 Å
R-Value Free:
0.239 (Depositor), 0.233 (DCC)
R-Value Work:
0.179 (Depositor), 0.181 (DCC)
R-Value Observed:
0.196 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 7LQP

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Rapid development of potent inhibitors of the HIV integrase-LEDGF interaction by fragment-linking using off-rate screening

Gorman, M.A., Parker, M.W.

To be published.

Macromolecule Content

Total Structure Weight: 38.41 kDa
Atom Count: 2,420
Modeled Residue Count: 289
Deposited Residue Count: 326
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Integrase	A, B	163	Human immunodeficiency virus 1	Mutation(s): 0
UniProt
Find proteins for P12497 (Human immunodeficiency virus type 1 group M subtype B (isolate NY5)) Explore P12497 Go to UniProtKB: P12497
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P12497
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
YAV (Subject of Investigation/LOI) Query on YAV Download:Ideal Coordinates CCD File SDF format, chain U [auth B] MOL2 format, chain U [auth B] mmCIF format, chain U [auth B]	U [auth B]	2-[2-[2-[3-[2-[2-[2-[[3-[2-[3-(2-hydroxy-2-oxoethyl)-5-methyl-1-benzofuran-2-yl]ethynyl]phenyl]carbonylamino]ethoxy]ethoxy]ethylcarbamoyl]phenyl]ethynyl]-5-methyl-1-benzofuran-3-yl]ethanoic acid C₄₆ H₄₀ N₂ O₁₀ CNJSVQQGSQPFLB-UHFFFAOYSA-N		Interactions Focus chain U [auth B] Interactions & Density Focus chain U [auth B]
IOD Query on IOD Download:Ideal Coordinates CCD File SDF format, chain N [auth B] SDF format, chain M [auth B] SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] SDF format, chain C [auth A] MOL2 format, chain N [auth B] MOL2 format, chain M [auth B] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] mmCIF format, chain N [auth B] mmCIF format, chain M [auth B] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A]	C [auth A] D [auth A] E [auth A] F [auth A] M [auth B] C [auth A], D [auth A], E [auth A], F [auth A], M [auth B], N [auth B]	IODIDE ION I XMBWDFGMSWQBCA-UHFFFAOYSA-M		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain M [auth B] Focus chain N [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain M [auth B] Focus chain N [auth B]
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain O [auth B] SDF format, chain Q [auth B] SDF format, chain R [auth B] SDF format, chain S [auth B] SDF format, chain T [auth B] SDF format, chain P [auth B] SDF format, chain H [auth A] MOL2 format, chain G [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain O [auth B] MOL2 format, chain Q [auth B] MOL2 format, chain R [auth B] MOL2 format, chain S [auth B] MOL2 format, chain T [auth B] MOL2 format, chain P [auth B] MOL2 format, chain H [auth A] mmCIF format, chain G [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain L [auth A] mmCIF format, chain O [auth B] mmCIF format, chain Q [auth B] mmCIF format, chain R [auth B] mmCIF format, chain S [auth B] mmCIF format, chain T [auth B] mmCIF format, chain P [auth B] mmCIF format, chain H [auth A]	G [auth A] H [auth A] I [auth A] J [auth A] K [auth A] G [auth A], H [auth A], I [auth A], J [auth A], K [auth A], L [auth A], O [auth B], P [auth B], Q [auth B], R [auth B], S [auth B], T [auth B]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Interactions & Density Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
CSO Query on CSO	A, B	L-PEPTIDE LINKING	C₃ H₇ N O₃ S		CYS

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.07 Å
R-Value Free: 0.239 (Depositor), 0.233 (DCC)
R-Value Work: 0.179 (Depositor), 0.181 (DCC)
R-Value Observed: 0.196 (Depositor)

Space Group: P 4₃

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 46.421	α = 90
b = 46.421	β = 90
c = 137.999	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
XDS	data scaling
PHENIX	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2022-02-23

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2022-02-23
Type: Initial release
Version 1.1: 2024-10-09
Changes: Data collection, Structure summary
