7LQ0

Crystal structures and ribonuclease activity of the Flavivirus host factor ERI3 that is involved in viral RNA synthesis define the ERI subfamily of structure-specific 3-prime - 5-prime exoribonucleases

• PDB DOI: https://doi.org/10.2210/pdb7LQ0/pdb

• Classification: HYDROLASE
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2021-02-12 Released: 2022-02-16
• Deposition Author(s): Thapar, R., Andrew, A.S., Tainer, J.A.
• Funding Organization(s): Robert A. Welch Foundation, National Institutes of Health/National Cancer Institute (NIH/NCI), Other private

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.60 Å
• R-Value Free: 0.199
• R-Value Work: 0.162
• R-Value Observed: 0.164

Literature

Crystal structures and ribonuclease activity of the Flavivirus host factor ERI3 that is involved in viral RNA synthesis define the ERI subfamily of structure-specific 3' - 5' exoribonucleases

Thapar, R., Arvai, A.S., Tainer, J.A.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 assigned by authors.

Macromolecule Content

• Total Structure Weight: 51.02 kDa
• Atom Count: 3,596
• Modelled Residue Count: 400
• Deposited Residue Count: 432
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
ERI1 exoribonuclease 3	A, B	216	Homo sapiens	Mutation(s): 0  Gene Names: ERI3, PINT1, PRNPIP, PRNPIP1 EC: 3.1
UniProt & NIH Common Fund Data Resources
Find proteins for O43414 (Homo sapiens) Explore O43414  Go to UniProtKB:  O43414
PHAROS:  O43414 GTEx:  ENSG00000117419

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
AMP (Subject of Investigation/LOI)	C [auth A], F [auth B]	ADENOSINE MONOPHOSPHATE C10 H14 N5 O7 P UDMBCSSLTHHNCD-KQYNXXCUSA-N
GOL	I [auth B]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
MG (Subject of Investigation/LOI)	D [auth A], E [auth A], G [auth B], H [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.60 Å
• R-Value Free: 0.199
• R-Value Work: 0.162
• R-Value Observed: 0.164
• Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 58.529	α = 90
b = 74.2	β = 90
c = 96.487	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
Blu-Ice	data collection
XDS	data reduction
XDS	data scaling
PHASER	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2022-02-16
Deposition Author(s): Thapar, R., Andrew, A.S., Tainer, J.A.

---

Funding Organization	Location	Grant Number
Robert A. Welch Foundation		--
National Institutes of Health/National Cancer Institute (NIH/NCI)	United States	CA220430
Other private	United States	GAP Award (to R.T., J.A.T)

Revision History

• Version 1.0: 2022-02-16
  Type: Initial release

• Version 1.1: 2023-10-18
  Changes: Data collection, Refinement description
