7LHY

Caenorhabditis elegans SWSN-4 (SMARCA4-BRG1) ATPase Bromodomain in complex with a modified histone H3, N6-epsilon-acetyl-L-lysine 14 (H3K14ac) polypeptide


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.30 Å
  • R-Value Free: 0.198
  • R-Value Work: 0.181
  • R-Value Observed: 0.182

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Binding specificity and function of the SWI/SNF subunit SMARCA4 bromodomain interaction with acetylated histone H3K14.

Enriquez, P.Krajewski, K.Strahl, B.D.Rothbart, S.B.Dowen, R.H.Rose, R.B.

(2021) J Biol Chem 297: 101145-101145

  • DOI: 10.1016/j.jbc.2021.101145
  • Primary Citation of Related Structures:
    7LHY

  • PubMed Abstract:
  • Bromodomains (BD) are conserved reader modules that bind acetylated lysine residues on histones. Although much has been learned regarding the in vitro properties of these domains, less is known about their function within chromatin complexes. SWI/SNF chromatin-remodeling complexes modulate transcription and contribute to DNA damage repair ...

    Bromodomains (BD) are conserved reader modules that bind acetylated lysine residues on histones. Although much has been learned regarding the in vitro properties of these domains, less is known about their function within chromatin complexes. SWI/SNF chromatin-remodeling complexes modulate transcription and contribute to DNA damage repair. Mutations in SWI/SNF subunits have been implicated in many cancers. Here we demonstrate that the BD of Caenorhabditis elegans SMARCA4/BRG1, a core SWI/SNF subunit, recognizes acetylated lysine 14 of histone H3 (H3K14ac), similar to its Homo sapiens ortholog. We identify the interactions of SMARCA4 with the acetylated histone peptide from a 1.29 Å-resolution crystal structure of the CeSMARCA4 BD-H3K14ac complex. Significantly, most of the SMARCA4 BD residues in contact with the histone peptide are conserved with other proteins containing family VIII bromodomains. Based on the premise that binding specificity is conserved among bromodomain orthologs, we propose that loop residues outside of the binding pocket position contact residues to recognize the H3K14ac sequence. CRISPR-Cas9-mediated mutations in the SMARCA4 BD that abolish H3K14ac binding in vitro had little or no effect on C. elegans viability or physiological function in vivo. However, combining SMARCA4 BD mutations with knockdown of the SWI/SNF accessory subunit PBRM-1 resulted in severe developmental defects in animals. In conclusion, we demonstrated an essential function for the SWI/SNF bromodomain in vivo and detected potential redundancy in epigenetic readers in regulating chromatin remodeling. These findings have implications for the development of small molecule BD inhibitors to treat cancers and other diseases.


    Organizational Affiliation

    Department of Molecular and Structural Biochemistry, North Carolina State University, Raleigh, NC, 27695-7622, USA. Electronic address: rbrose2@ncsu.edu.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
SWI/SNF nucleosome remodeling complex componentA123Caenorhabditis elegansMutation(s): 0
Gene Names: swsn-4psa-4CELE_F01G4.1F01G4.1
UniProt
Find proteins for G5EF53 (Caenorhabditis elegans)
Explore G5EF53
Go to UniProtKB:  G5EF53
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG5EF53
Protein Feature View
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
H3(7-20)K14acB14Caenorhabditis elegansMutation(s): 0
Gene Names:
EC: 3.6.4.12
UniProt
Find proteins for P08898 (Caenorhabditis elegans)
Explore P08898
Go to UniProtKB:  P08898
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP08898
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
ALY
Query on ALY
B L-PEPTIDE LINKINGC8 H16 N2 O3LYS
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.30 Å
  • R-Value Free: 0.198
  • R-Value Work: 0.181
  • R-Value Observed: 0.182
  • Space Group: P 41 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 69.064α = 90
b = 69.064β = 90
c = 55.32γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
SCALEPACKdata scaling
PHASERphasing

Structure Validation

View Full Validation Report




Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Science Foundation (NSF, United States)United StatesDUE-1643814

Revision History  (Full details and data files)

  • Version 1.0: 2021-09-08
    Type: Initial release
  • Version 1.1: 2021-09-15
    Changes: Database references
  • Version 1.2: 2021-11-10
    Changes: Database references
