7KRG | pdb_00007krg

Crystal Structure of Mannitol Dehydrogenase (ChMDH) from Cladosporium herbarum in complex with NADP+ and Na


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.04 Å
  • R-Value Free:
    0.183 (Depositor), 0.183 (DCC)
  • R-Value Work:
    0.154 (Depositor), 0.155 (DCC)
  • R-Value Observed:
    0.155 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7KRG

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

Biochemical and clinical studies of putative allergens to assess what distinguishes them from other non-allergenic proteins in the same family.

Glenn, K.C.Silvanovich, A.Lee, S.G.Allen, A.Park, S.Dunn, S.E.Kessenich, C.Meng, C.Vicini, J.L.Jez, J.M.

(2022) Transgenic Res 31: 507-524

  • DOI: https://doi.org/10.1007/s11248-022-00316-8
  • Primary Citation Related Structures:
    7KQV, 7KRG

  • PubMed Abstract:

    Many protein families have numerous members listed in databases as allergens; however, some allergen database entries, herein called "orphan allergens", are members of large families of which all other members are not allergens. These orphan allergens provide an opportunity to assess whether specific structural features render a protein allergenic. Three orphan allergens [Cladosporium herbarum aldehyde dehydrogenase (ChALDH), Alternaria alternata ALDH (AaALDH), and C. herbarum mannitol dehydrogenase (ChMDH)] were recombinantly produced and purified for structure characterization and for clinical skin prick testing (SPT) in mold allergic participants. Examination of the X-ray crystal structures of ChALDH and ChMDH and a homology structure model of AaALDH did not identify any discernable epitopes that distinguish these putative orphan allergens from their non-allergenic protein relatives. SPT results were aligned with ChMDH being an allergen, 53% of the participants were SPT (+). AaALDH did not elicit SPT reactivity above control proteins not in allergen databases (i.e., Psedomonas syringae indole-3-acetaldehyde dehydrogenase and Zea mays ALDH). Although published results showed consequential human IgE reactivity with ChALDH, no SPT reactivity was observed in this study. With only one of these three orphan allergens, ChMDH, eliciting SPT(+) reactions consistent with the protein being included in allergen databases, this underscores the complicated nature of how bioinformatics is used to assess the potential allergenicity of food proteins that could be newly added to human diets and, when needed, the subsequent clinical testing of that bioinformatic assessment.Trial registration number and date of registration AAC-2017-0467, approved as WIRB protocol #20172536 on 07DEC2017 by WIRB-Copernicus (OHRP/FDA Registration #: IRB00000533, organization #: IORG0000432).


  • Organizational Affiliation
    • Bayer Crop Science, 700 Chesterfield Pkwy W, Chesterfield, MO, 63017, USA.

Macromolecule Content

  • Total Structure Weight: 236.27 kDa
  • Atom Count: 17,725
  • Modeled Residue Count: 2,128
  • Deposited Residue Count: 2,160
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
NADP-dependent mannitol dehydrogenase
A, B, C, D, E
A, B, C, D, E, F, G, H
270Cladosporium herbarumMutation(s): 0
EC: 1.1.1.138
UniProt
Find proteins for P0C0Y5 (Davidiella tassiana)
Explore P0C0Y5
Go to UniProtKB:  P0C0Y5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0C0Y5
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
NAP
(Subject of Investigation/LOI)

Query on NAP



Download:Ideal Coordinates CCD File
J [auth A]
L [auth B]
M [auth C]
N [auth D]
P [auth E]
J [auth A],
L [auth B],
M [auth C],
N [auth D],
P [auth E],
Q [auth F],
S [auth G],
T [auth H]
NADP NICOTINAMIDE-ADENINE-DINUCLEOTIDE PHOSPHATE
C21 H28 N7 O17 P3
XJLXINKUBYWONI-NNYOXOHSSA-N
NA
(Subject of Investigation/LOI)

Query on NA



Download:Ideal Coordinates CCD File
I [auth A],
K [auth B],
O [auth E],
R [auth G]
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.04 Å
  • R-Value Free:  0.183 (Depositor), 0.183 (DCC)
  • R-Value Work:  0.154 (Depositor), 0.155 (DCC)
  • R-Value Observed: 0.155 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 88.867α = 90
b = 119.322β = 94.884
c = 111.211γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
PHENIXrefinement
SBC-Collectdata collection
Cootmodel building
HKL-3000data scaling
PHASERphasing
HKL-3000data reduction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Science Foundation (NSF, United States)United States--

Revision History  (Full details and data files)

  • Version 1.0: 2022-02-23
    Type: Initial release
  • Version 1.1: 2023-09-06
    Changes: Data collection, Database references
  • Version 1.2: 2023-10-18
    Changes: Refinement description
