7KIN | pdb_00007kin

Mycobacterium tuberculosis WT RNAP transcription open promoter complex with WhiB7 promoter


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.74 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 7KIN

This is version 1.3 of the entry. See complete history

Literature

Structural basis of transcriptional activation by the Mycobacterium tuberculosis intrinsic antibiotic-resistance transcription factor WhiB7.

Lilic, M.Darst, S.A.Campbell, E.A.

(2021) Mol Cell 81: 2875-2886.e5

  • DOI: https://doi.org/10.1016/j.molcel.2021.05.017
  • Primary Citation Related Structures:
    7KIF, 7KIM, 7KIN

  • PubMed Abstract:

    In pathogenic mycobacteria, transcriptional responses to antibiotics result in induced antibiotic resistance. WhiB7 belongs to the Actinobacteria-specific family of Fe-S-containing transcription factors and plays a crucial role in inducible antibiotic resistance in mycobacteria. Here, we present cryoelectron microscopy structures of Mycobacterium tuberculosis transcriptional regulatory complexes comprising RNA polymerase σ A -holoenzyme, global regulators CarD and RbpA, and WhiB7, bound to a WhiB7-regulated promoter. The structures reveal how WhiB7 interacts with σ A -holoenzyme while simultaneously interacting with an AT-rich sequence element via its AT-hook. Evidently, AT-hooks, rare elements in bacteria yet prevalent in eukaryotes, bind to target AT-rich DNA sequences similarly to the nuclear chromosome binding proteins. Unexpectedly, a subset of particles contained a WhiB7-stabilized closed promoter complex, revealing this intermediate's structure, and we apply kinetic modeling and biochemical assays to rationalize how WhiB7 activates transcription. Altogether, our work presents a comprehensive view of how WhiB7 serves to activate gene expression leading to antibiotic resistance.


  • Organizational Affiliation
    • Laboratory of Molecular Biophysics, The Rockefeller University, 1230 York Avenue, New York, NY 10065, USA.

Macromolecule Content

  • Total Structure Weight: 514.41 kDa
  • Atom Count: 29,379
  • Modeled Residue Count: 3,612
  • Deposited Residue Count: 4,295
  • Unique protein chains: 7
  • Unique nucleic acid chains: 2

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit alpha
A, B
347Mycobacterium tuberculosisMutation(s): 0
Gene Names: rpoA
EC: 2.7.7.6
UniProt
Find proteins for P9WGZ1 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv))
Explore P9WGZ1
Go to UniProtKB:  P9WGZ1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP9WGZ1
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit beta1,172Mycobacterium tuberculosisMutation(s): 0
Gene Names: rpoBMRA_0676
EC: 2.7.7.6
UniProt
Find proteins for P9WGY9 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv))
Explore P9WGY9
Go to UniProtKB:  P9WGY9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP9WGY9
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit beta'1,318Mycobacterium tuberculosisMutation(s): 0
Gene Names: rpoCE5M52_05480ERS007665_00591ERS013471_00574ERS023446_00410ERS075361_00813ERS094182_01340F6W99_03342
EC: 2.7.7.6
UniProt
Find proteins for P9WGY7 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv))
Explore P9WGY7
Go to UniProtKB:  P9WGY7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP9WGY7
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit omega110Mycobacterium tuberculosisMutation(s): 0
Gene Names: rpoZERS007703_04032ERS007720_04749ERS094182_01030
EC: 2.7.7.6
UniProt
Find proteins for P9WGY5 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv))
Explore P9WGY5
Go to UniProtKB:  P9WGY5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP9WGY5
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 5
MoleculeChains  Sequence LengthOrganismDetailsImage
RNA polymerase sigma factor SigA528Mycobacterium tuberculosisMutation(s): 0
Gene Names: sigAERDMAN_2966
UniProt
Find proteins for P9WGI1 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv))
Explore P9WGI1
Go to UniProtKB:  P9WGI1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP9WGI1
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 6
MoleculeChains  Sequence LengthOrganismDetailsImage
RNA polymerase-binding protein RbpAG [auth J]111Mycobacterium tuberculosisMutation(s): 0
Gene Names: rbpA
UniProt
Find proteins for P9WHJ5 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv))
Explore P9WHJ5
Go to UniProtKB:  P9WHJ5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP9WHJ5
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 7
MoleculeChains  Sequence LengthOrganismDetailsImage
RNA polymerase-binding transcription factor CarDH [auth M]162Mycobacterium tuberculosisMutation(s): 0
Gene Names: carD
UniProt
Find proteins for P9WJG3 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv))
Explore P9WJG3
Go to UniProtKB:  P9WJG3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP9WJG3
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 8
MoleculeChains LengthOrganismImage
DNA (54-MER)I [auth O]100Mycobacterium tuberculosis
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 9
MoleculeChains LengthOrganismImage
DNA (49-MER)J [auth P]100Mycobacterium tuberculosis
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.74 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United States--

Revision History  (Full details and data files)

  • Version 1.0: 2021-04-21
    Type: Initial release
  • Version 1.1: 2021-11-03
    Changes: Database references
  • Version 1.2: 2024-05-29
    Changes: Data collection
  • Version 1.3: 2025-05-21
    Changes: Data collection, Structure summary
