7JWG | pdb_00007jwg

OspA-Fab 221-7 complex structure


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.05 Å
  • R-Value Free:
    0.306 (Depositor), 0.303 (DCC)
  • R-Value Work:
    0.269 (Depositor), 0.268 (DCC)
  • R-Value Observed:
    0.271 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7JWG

This is version 1.3 of the entry. See complete history

Literature

Blocking Borrelia burgdorferi transmission from infected ticks to nonhuman primates with a human monoclonal antibody.

Schiller, Z.A.Rudolph, M.J.Toomey, J.R.Ejemel, M.LaRochelle, A.Davis, S.A.Lambert, H.S.Kern, A.Tardo, A.C.Souders, C.A.Peterson, E.Cannon, R.D.Ganesa, C.Fazio, F.Mantis, N.J.Cavacini, L.A.Sullivan-Bolyai, J.Hu, L.T.Embers, M.E.Klempner, M.S.Wang, Y.

(2021) J Clin Invest 131

  • DOI: https://doi.org/10.1172/JCI144843
  • Primary Citation Related Structures:
    7JWG

  • PubMed Abstract:

    Disrupting transmission of Borrelia burgdorferi sensu lato complex (B. burgdorferi) from infected ticks to humans is one strategy to prevent the significant morbidity from Lyme disease. We have previously shown that an anti-OspA human mAb, 2217, prevents transmission of B. burgdorferi from infected ticks in animal models. Maintenance of a protective plasma concentration of a human mAb for tick season presents a significant challenge for a preexposure prophylaxis strategy. Here, we describe the optimization of mAb 2217 by amino acid substitutions (2217LS: M428L and N434S) in the Fc domain. The LS mutation led to a 2-fold increase in half-life in cynomolgus monkeys. In a rhesus macaque model, 2217LS protected animals from tick transmission of spirochetes at a dose of 3 mg/kg. Crystallographic analysis of Fab in complex with OspA revealed that 2217 bound an epitope that was highly conserved among the B. burgdorferi, B. garinii, and B. afzelii species. Unlike most vaccines that may require boosters to achieve protection, our work supports the development of 2217LS as an effective preexposure prophylaxis in Lyme-endemic regions, with a single dose at the beginning of tick season offering immediate protection that remains for the duration of exposure risk.


  • Organizational Affiliation
    • MassBiologics of the University of Massachusetts Medical School, Boston, Massachusetts, USA.

Macromolecule Content

  • Total Structure Weight: 146.56 kDa
  • Atom Count: 10,230
  • Modeled Residue Count: 1,343
  • Deposited Residue Count: 1,356
  • Unique protein chains: 3

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Antibody 221-7 Fab heavy chainA [auth H],
D [auth A]
220Homo sapiensMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Antibody 221-7 Fab light chainB [auth L],
E [auth B]
207Homo sapiensMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Outer surface protein AC,
F [auth E]
251Borreliella burgdorferi B31Mutation(s): 0
Gene Names: ospABB_A15
UniProt
Find proteins for P0CL66 (Borreliella burgdorferi (strain ATCC 35210 / DSM 4680 / CIP 102532 / B31))
Explore P0CL66
Go to UniProtKB:  P0CL66
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0CL66
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.05 Å
  • R-Value Free:  0.306 (Depositor), 0.303 (DCC)
  • R-Value Work:  0.269 (Depositor), 0.268 (DCC)
  • R-Value Observed: 0.271 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 173.383α = 90
b = 99.263β = 103.49
c = 121.616γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
PHASERphasing
PHENIXrefinement
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2021-09-08
    Type: Initial release
  • Version 1.1: 2022-03-23
    Changes: Database references
  • Version 1.2: 2023-10-18
    Changes: Data collection, Refinement description
  • Version 1.3: 2024-11-20
    Changes: Structure summary
