7JTF | pdb_00007jtf

Structure of Hepatitis C Virus Envelope Glycoprotein E2 core from genotype 6a bound to broadly neutralizing antibody RM2-01

• PDB DOI: https://doi.org/10.2210/pdb7JTF/pdb

• Classification: IMMUNE SYSTEM/VIRAL PROTEIN
• Organism(s): Macaca mulatta, Recombinant Hepatitis C virus HK6a/JFH-1
• Expression System: Homo sapiens
• Mutation(s): Yes


• Deposited: 2020-08-17 Released: 2021-03-10
• Deposition Author(s): Tzarum, N., Wilson, I.A., Law, M.
• Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 3.35 Å
• R-Value Free:
  0.296 (Depositor), 0.295 (DCC)
• R-Value Work:
  0.242 (Depositor), 0.244 (DCC)
• R-Value Observed:
  0.245 (Depositor)

Starting Model: experimental

Literature

HCV Env immunization elicits a rapid VH1-69-like broadly neutralizing antibody response in rhesus macaques

Tzarum, N., Chen, F., Lin, X., Giang, E., Velazquez-Moctezuma, R., Augestad, E.H., Nagy, K., He, L., Davidson, E., Chavez, D., Prentoe, J., Stanfield, R.L., Lanford, R., Bukh, J., Wilson, I.A., Zhu, J., Law, M.

(2021) Immunity

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 3-mer - A1B1C1 Pseudo Symmetry: Asymmetric - C1
Pseudo Stoichiometry: Hetero 3-mer - A2B1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 3-mer - A1B1C1 Pseudo Symmetry: Asymmetric - C1
Pseudo Stoichiometry: Hetero 3-mer - A2B1

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 136.53 kDa
• Atom Count: 8,617
• Modeled Residue Count: 1,123
• Deposited Residue Count: 1,264
• Unique protein chains: 3

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
RM2-01 Fab heavy chain	A, D [auth C]	229	Macaca mulatta	Mutation(s): 0

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
RM2-01 Fab light chain	B, E [auth D]	214	Macaca mulatta	Mutation(s): 0

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Envelope glycoprotein E2	C [auth E], F	189	Recombinant Hepatitis C virus HK6a/JFH-1	Mutation(s): 1
UniProt
Find proteins for B9V0E2 (Recombinant Hepatitis C virus HK6a/JFH-1) Explore B9V0E2  Go to UniProtKB:  B9V0E2

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 3.35 Å
• R-Value Free:  0.296 (Depositor), 0.295 (DCC)
• R-Value Work:  0.242 (Depositor), 0.244 (DCC)
• R-Value Observed: 0.245 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 89.732	α = 90
b = 64.887	β = 105.155
c = 145.208	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB_EXTRACT	data extraction
HKL-2000	data reduction
Blu-Ice	data collection
PHASER	phasing
SCALEPACK	data scaling

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2021-03-10
Deposition Author(s): Tzarum, N., Wilson, I.A., Law, M.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	Al123365
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	Al106005

Revision History

• Version 1.0: 2021-03-10
  Type: Initial release

• Version 1.1: 2023-10-18
  Changes: Data collection, Database references, Refinement description
• Version 1.2: 2024-10-23
  Changes: Structure summary
