7JRG | pdb_00007jrg

Plant Mitochondrial complex III2 from Vigna radiata


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.20 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Starting Models: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7JRG

This is version 1.2 of the entry. See complete history

Literature

Atomic structures of respiratory complex III 2 , complex IV, and supercomplex III 2 -IV from vascular plants.

Maldonado, M.Guo, F.Letts, J.A.

(2021) Elife 10

  • DOI: https://doi.org/10.7554/eLife.62047
  • Primary Citation Related Structures:
    7JRG, 7JRO, 7JRP

  • PubMed Abstract:

    Mitochondrial complex III (CIII 2 ) and complex IV (CIV), which can associate into a higher-order supercomplex (SC III 2 +IV), play key roles in respiration. However, structures of these plant complexes remain unknown. We present atomic models of CIII 2 , CIV, and SC III 2 +IV from Vigna radiata determined by single-particle cryoEM. The structures reveal plant-specific differences in the MPP domain of CIII 2 and define the subunit composition of CIV. Conformational heterogeneity analysis of CIII 2 revealed long-range, coordinated movements across the complex, as well as the motion of CIII 2 's iron-sulfur head domain. The CIV structure suggests that, in plants, proton translocation does not occur via the H channel. The supercomplex interface differs significantly from that in yeast and bacteria in its interacting subunits, angle of approach and limited interactions in the mitochondrial matrix. These structures challenge long-standing assumptions about the plant complexes and generate new mechanistic hypotheses.


  • Organizational Affiliation
    • Department of Molecular and Cellular Biology, University of California Davis, Davis, United States.

Macromolecule Content

  • Total Structure Weight: 570.54 kDa
  • Atom Count: 32,930
  • Modeled Residue Count: 3,983
  • Deposited Residue Count: 4,838
  • Unique protein chains: 10

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Mitochondrial-processing peptidase subunit beta, mitochondrial isoform X1A,
K [auth M]
527Vigna radiata var. radiataMutation(s): 0
EC: 3.4.24.64
UniProt
Find proteins for A0A1S3TWG4 (Vigna radiata var. radiata)
Explore A0A1S3TWG4
Go to UniProtKB:  A0A1S3TWG4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A1S3TWG4
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Alpha-MPPB,
L [auth N]
506Vigna radiata var. radiataMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for A0A1S3VF71 (Vigna radiata var. radiata)
Explore A0A1S3VF71
Go to UniProtKB:  A0A1S3VF71
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A1S3VF71
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
COBC,
M [auth O]
393Vigna radiata var. radiataMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
cytochrome c1-2, heme protein, mitochondrialD,
N [auth P]
306Vigna radiata var. radiataMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for A0A1S3W199 (Vigna radiata var. radiata)
Explore A0A1S3W199
Go to UniProtKB:  A0A1S3W199
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A1S3W199
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 5
MoleculeChains  Sequence LengthOrganismDetailsImage
Cytochrome b-c1 complex subunit Rieske, mitochondrialE,
O [auth Q]
271Vigna radiata var. radiataMutation(s): 0
EC: 7.1.1.8
Membrane Entity: Yes
UniProt
Find proteins for A0A1S3TB49 (Vigna radiata var. radiata)
Explore A0A1S3TB49
Go to UniProtKB:  A0A1S3TB49
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A1S3TB49
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 6
MoleculeChains  Sequence LengthOrganismDetailsImage
Cytochrome b-c1 complex subunit 7F,
P [auth R]
122Vigna radiata var. radiataMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for A0A1S3U9J1 (Vigna radiata var. radiata)
Explore A0A1S3U9J1
Go to UniProtKB:  A0A1S3U9J1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A1S3U9J1
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 7
MoleculeChains  Sequence LengthOrganismDetailsImage
cytochrome b-c1 complex subunit 8G,
Q [auth S]
72Vigna radiata var. radiataMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for A0A1S3U9S5 (Vigna radiata var. radiata)
Explore A0A1S3U9S5
Go to UniProtKB:  A0A1S3U9S5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A1S3U9S5
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 8
MoleculeChains  Sequence LengthOrganismDetailsImage
Cytochrome b-c1 complex subunit 6H,
R [auth T]
69Vigna radiata var. radiataMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for A0A1S3VHC0 (Vigna radiata var. radiata)
Explore A0A1S3VHC0
Go to UniProtKB:  A0A1S3VHC0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A1S3VHC0
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 9
MoleculeChains  Sequence LengthOrganismDetailsImage
cytochrome b-c1 complex subunit 9I [auth J],
S [auth V]
72Vigna radiata var. radiataMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for A0A1S3TQD2 (Vigna radiata var. radiata)
Explore A0A1S3TQD2
Go to UniProtKB:  A0A1S3TQD2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A1S3TQD2
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 10
MoleculeChains  Sequence LengthOrganismDetailsImage
QCR10J [auth K],
T [auth W]
81Vigna radiata var. radiataMutation(s): 0

Small Molecules

Ligands 6 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
CDL

Query on CDL



Download:Ideal Coordinates CCD File
AB [auth P]
CB [auth S]
GA [auth C]
IA [auth D]
OA [auth M]
AB [auth P],
CB [auth S],
GA [auth C],
IA [auth D],
OA [auth M],
RA [auth O],
VA [auth O],
W [auth A],
X [auth C]
CARDIOLIPIN
C81 H156 O17 P2
XVTUQDWPJJBEHJ-KZCWQMDCSA-L
PC1

Query on PC1



Download:Ideal Coordinates CCD File
BB [auth S],
PA [auth M],
V [auth A]
1,2-DIACYL-SN-GLYCERO-3-PHOSPHOCHOLINE
C44 H88 N O8 P
NRJAVPSFFCBXDT-HUESYALOSA-N
3PE

Query on 3PE



Download:Ideal Coordinates CCD File
AA [auth C]
BA [auth C]
CA [auth C]
DA [auth C]
DB [auth W]
AA [auth C],
BA [auth C],
CA [auth C],
DA [auth C],
DB [auth W],
EA [auth C],
EB [auth W],
FA [auth C],
JA [auth F],
KA [auth F],
LA [auth G],
NA [auth M],
QA [auth O],
UA [auth O],
WA [auth O],
XA [auth O],
YA [auth O]
1,2-Distearoyl-sn-glycerophosphoethanolamine
C41 H82 N O8 P
LVNGJLRDBYCPGB-LDLOPFEMSA-N
HEC

Query on HEC



Download:Ideal Coordinates CCD File
HA [auth D],
ZA [auth P]
HEME C
C34 H34 Fe N4 O4
HXQIYSLZKNYNMH-LJNAALQVSA-N
HEM

Query on HEM



Download:Ideal Coordinates CCD File
SA [auth O],
TA [auth O],
Y [auth C],
Z [auth C]
PROTOPORPHYRIN IX CONTAINING FE
C34 H32 Fe N4 O4
KABFMIBPWCXCRK-RGGAHWMASA-L
ZN

Query on ZN



Download:Ideal Coordinates CCD File
MA [auth M],
U [auth A]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.20 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONcryoSPARC
MODEL REFINEMENTPHENIX

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2021-01-20
    Type: Initial release
  • Version 1.1: 2021-02-03
    Changes: Database references
  • Version 1.2: 2024-11-20
    Changes: Data collection, Database references, Derived calculations, Refinement description, Structure summary
