7JJ0 | pdb_00007jj0

GTP-specific succinyl-CoA synthetase complexed with Mg-GMPPCP

• PDB DOI: https://doi.org/10.2210/pdb7JJ0/pdb

• Classification: LIGASE
• Organism(s): Sus scrofa
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2020-07-24 Released: 2021-03-10
• Deposition Author(s): Huang, J., Fraser, M.E.
• Funding Organization(s): Natural Sciences and Engineering Research Council (NSERC, Canada)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.25 Å
• R-Value Free:
  0.265 (Depositor), 0.260 (DCC)
• R-Value Work:
  0.235 (Depositor), 0.230 (DCC)
• R-Value Observed:
  0.236 (Depositor)

Starting Model: experimental

Literature

Second distinct conformation of the phosphohistidine loop in succinyl-CoA synthetase

Huang, J., Fraser, M.E.

(2021) Acta Crystallogr D Biol Crystallogr 77: 357-368

• DOI: https://doi.org/10.1107/S2059798321000334

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 2-mer - A1B1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 2-mer - A1B1

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 150 kDa
• Atom Count: 10,375
• Modeled Residue Count: 1,368
• Deposited Residue Count: 1,400
• Unique protein chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Succinate--CoA ligase [ADP/GDP-forming] subunit alpha, mitochondrial	A, C	305	Sus scrofa	Mutation(s): 0  Gene Names: SUCLG1 EC: 6.2.1.4 (PDB Primary Data), 6.2.1.5 (PDB Primary Data)
UniProt
Find proteins for O19069 (Sus scrofa) Explore O19069  Go to UniProtKB:  O19069

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Succinate--CoA ligase [GDP-forming] subunit beta, mitochondrial	B, D	395	Sus scrofa	Mutation(s): 0  Gene Names: SUCLG2 EC: 6.2.1.4
UniProt
Find proteins for P53590 (Sus scrofa) Explore P53590  Go to UniProtKB:  P53590

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GCP (Subject of Investigation/LOI)	E [auth B]	PHOSPHOMETHYLPHOSPHONIC ACID GUANYLATE ESTER C11 H18 N5 O13 P3 PHBDHXOBFUBCJD-KQYNXXCUSA-N
MG	F [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.25 Å
• R-Value Free:  0.265 (Depositor), 0.260 (DCC)
• R-Value Work:  0.235 (Depositor), 0.230 (DCC)
• R-Value Observed: 0.236 (Depositor)

Space Group: P 3₂

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 99.311	α = 90
b = 99.311	β = 90
c = 133.512	γ = 120

Software Package:

Software Name	Purpose
xia2	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
xia2	data reduction
PHASER	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2021-03-10
Deposition Author(s): Huang, J., Fraser, M.E.

---

Funding Organization	Location	Grant Number
Natural Sciences and Engineering Research Council (NSERC, Canada)	Canada	04815-2019

Revision History

• Version 1.0: 2021-03-10
  Type: Initial release

• Version 1.1: 2023-10-18
  Changes: Data collection, Database references, Refinement description
